C0730

CONNECTOR

DEFENDER 1999 MY

Relay - Fuel pump

Female
BLACK

Behind centre of fascia

P5660

C0068

C0730

C0151

C0731

C0044

C0282

Cav

Col

CCT

2

PW

21

4

NO

21

6

UP

21

8

PW

21

CONNECTOR

C0731

DEFENDER 1999 MY

Relay - Sounder - Alarm

Female
BLACK

Behind centre of fascia

P5660

C0068

C0730

C0151

C0731

C0044

C0282

Cav

Col

CCT

2

OB

15

4

OW

15

5

OR

15

6

NU

15

8

NU

15

C0735

CONNECTOR

DEFENDER 1999 MY

Sensor - Water filter

Female
LIGHT GREY

Below RH rear wheelarch

P5583

C0735

Cav

Col

CCT

1

OG

21

2

B

21

3

WG

21

CONNECTOR

C0786

DEFENDER 1999 MY

Main harness to air
conditioning (A/C) harness

Female
BROWN

Behind centre of fascia

P5643

C0786

C0277

Cav

Col

CCT

1

WG

1

3

YS

21

3

BS

22

4

PB

21

4

BP

22

5

RO

1

6

NP

1

7

B

1
