CONNECTOR DETAILS

DEFENDER 90 NAS

C649

C649
MAIN HARNESS TO
SPEED SENSE
HARNESS
4 Way
Female
BLACK
Beneath front passenger's
seat

Cav

Color Cct

1

G

ALL

2

G

ALL

3

G

ALL

4

G

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C662

C662
DIODE

BLACK
Above gearbox

t:\compuset\erl\faceview\YQP10003.tif

Cav

Color Cct

1

B

ALL

2

SB

ALL

CONNECTOR DETAILS

DEFENDER 90 NAS

C668

C668
MAIN HARNESS TO
GEAR BOX HARNESS
6 Way
Female
BLACK
Behind center console

Cav

Color Cct

1

BY

ALL

2

GP

ALL

3

B

ALL

4

B

ALL

5

KS

ALL

6

KS

ALL

   CONNECTOR DETAILS

DEFENDER 90 NAS

C671

C671
KEY LOCK SOLENOID

BLACK
Behind instrument pack

t:\compuset\erl\faceview\YPQ10020.tif

Cav

Color Cct

1

BR

ALL

2

BY

ALL
