Jeep Wrangler (2018 year). Instruction

NOTE:

For emergency exit with the system engaged, move

the lock lever rearward (located on the door trim panel),

roll down the window and open the door with the outside

door handle.

Front Door Removal

WARNING!

Do not drive your vehicle on public roads with the
doors removed as you will lose the protection they can
provide. This procedure is furnished for use during
off-road operation only.

WARNING!

All occupants must wear seat belts during off-road
operation with doors removed.

NOTE:
• Doors are heavy; use caution when removing them.
• Hinge pin can break if overtightened during door

reinstall (Max Torque: 10 N·m / 7.5 ft· lb).

Door Removal Warning Label

GETTING TO KNOW YOUR VEHICLE

1. Roll down the glass window to prevent any damage.
2. Remove the hinge pin screws from the upper and lower

outside hinges (using a #T50 Torx head driver).

NOTE:

The hinge pin screws and nuts can be stowed in

the rear cargo tray located under the rear loadfloor.

3. Remove the check screw from the center door check

(using a #T40 Torx head driver).

Hinge Pin Screw

Door Check (Detached)

GETTING TO KNOW YOUR VEHICLE

4. Remove the plastic wiring access door under the instru-

ment panel by sliding the plastic panel along the door

frame toward the seats until the tabs are detached.

NOTE:

Do not pry back to open, as this will break the

plastic cover.
5. Pull up on the red locking tab to unlock the wiring

harness.

6. Push and hold down the black security tab under the

wiring harness, and lift the harness into the open

position.

Wiring Access Door

Closed Wiring Harness

1 – Locking Tab
2 – Wiring Harness

GETTING TO KNOW YOUR VEHICLE

7. With the wiring harness open, pull downward on the

wiring connector to unplug. Store wiring connector in

the lower door basket.

8. With the door open, lift the door to clear the hinge pins

from their hinges and remove the door.

To reinstall the door(s), perform the previous steps in the

opposite order.

NOTE:

The upper hinge has a longer pin, which can be

used to assist in guiding the door into place when rein-

stalling.

Rear Door Removal (Four-Door Models)

WARNING!

Do not drive your vehicle on public roads with the
doors removed as you will lose the protection they can
provide. This procedure is furnished for use during
off-road operation only.

Open Wiring Harness

1 – Wiring Harness
2 – Security Tab

Door Removal Warning Label

GETTING TO KNOW YOUR VEHICLE

WARNING!

All occupants must wear seat belts during off-road
operation with doors removed.

NOTE:
• Doors are heavy; use caution when removing them.
• Hinge pin can break if overtightened during door

reinstall (Max Torque: 10 N·m / 7.5 ft· lb).

1. Roll down the glass window to prevent any damage.
2. Remove the hinge pin screws from the upper and lower

outside hinges (using a #T50 Torx head driver).

NOTE:

The hinge pin screws and nuts can be stowed in the

rear cargo tray located under the rear load floor.

Hinge Pin Screw

GETTING TO KNOW YOUR VEHICLE

3. Remove the check screw from the center door check

(using a #T40 Torx head driver).

4. Slide the front seat(s) fully forward.
5. Pry open and remove the plastic wiring access door

from the bottom of the B-pillar.

6. Unplug the wiring connector.

NOTE:

Squeeze the tab on the base of the wiring harness.

This will unlock the connector tab, allowing the wiring

connector to be unplugged.

Door Check (Attached)

Wiring Access Door

GETTING TO KNOW YOUR VEHICLE

7. With the door open, lift the door to clear the hinge pins

from their hinges and remove the door.

To reinstall the door(s), perform the previous steps in the

reverse order.

NOTE:

The upper hinge has a longer pin, which can be

used to assist in guiding the door into place when rein-

stalling.

SEATS

Seats are a part of the Occupant Restraint System of the

vehicle.

WARNING!

• It is dangerous to ride in a cargo area, inside or outside

of a vehicle. In a collision, people riding in these areas
are more likely to be seriously injured or killed.

• Do not allow people to ride in any area of your

vehicle that is not equipped with seats and seat belts.
In a collision, people riding in these areas are more
likely to be seriously injured or killed.

• Be sure everyone in your vehicle is in a seat and

using a seat belt properly.

Manual Front Seats

Front Seat Adjustment

The seat can be adjusted forward or rearward by using a

bar located by the front of the seat cushion, near the floor.

While sitting in the seat, lift up on the bar located under the

seat cushion and move the seat forward or rearward.

Release the bar once you have reached the desired position.

Then, using body pressure, move forward and rearward on

the seat to be sure that the seat adjusters have latched.

Wiring Connector

GETTING TO KNOW YOUR VEHICLE

WARNING!

• Adjusting a seat while driving may be dangerous.

Moving a seat while driving could result in loss of
control which could cause a collision and serious
injury or death.

• Seats should be adjusted before fastening the seat

belts and while the vehicle is parked. Serious injury or
death could result from a poorly adjusted seat belt.

Manual Seat Height Adjustment

The driver’s seat height can be raised or lowered by using

the ratcheting handle, located on the outboard side of the

seat. Pull upward on the handle to raise the seat, push

downward on the handle to lower the seat. Several strokes

may be necessary to achieve the desired position.

Adjustment Bar Location

Seat Height Adjustment

GETTING TO KNOW YOUR VEHICLE

Front Seatback Recline

To recline the seat, pull on the recline strap and lean

forward or backward, depending on the direction you

would like the seatback to move. Release the strap when

the desired position is reached and the seatback will lock

into place.

WARNING!

Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest. In
a collision you could slide under the seat belt, which
could result in serious injury or death.

Lumbar Support

The lumbar control knob is located on the outboard side of the

front driver seat. Rotate the control forward to increase and

rearward to decrease the desired amount of lumbar support.

Recline Strap

Lumbar Control Knob

GETTING TO KNOW YOUR VEHICLE

Heated Seats — If Equipped

The heated seats control buttons are located on the center

instrument panel below the touchscreen, and are also

located within the climate or controls screen of the touch-

screen.

• Push the heated seat button

once to turn the HI

setting on.

• Push the heated seat button

a second time to turn

the MED setting on.

• Push the heated seat button

a third time to turn the

LO setting on.

• Push the heated seat button

a fourth time to turn the

heating elements off.

NOTE:
• The engine must be running for the heated seats to

operate.

• The level of heat selected will stay on until the operator

changes it.

Vehicles Equipped With Remote Start

On models that are equipped with remote start, the driver’s

seat can be programmed to come on during a remote start.
This feature can be programmed through the Uconnect

system. Refer to “Uconnect Settings” in “Multimedia” for

further information.

Heated Seat Buttons

GETTING TO KNOW YOUR VEHICLE

WARNING!

• Persons who are unable to feel pain to the skin

because of advanced age, chronic illness, diabetes,
spinal cord injury, medication, alcohol use, exhaus-
tion or other physical condition must exercise care
when using the seat heater. It may cause burns even
at low temperatures, especially if used for long
periods of time

• Do not place anything on the seat or seatback that

insulates against heat, such as a blanket or cushion.
This may cause the seat heater to overheat. Sitting in
a seat that has been overheated could cause serious
burns due to the increased surface temperature of the
seat.

Front Passenger Easy Entry Seat — Two Door
Models

Pull upward on the easy entry lever located on the out-

board side of the seat back, and slide the entire seat

forward.

To return the seat to a sitting position, fold the seatback

upright until it locks and push the seat rearward until the

track locks.

NOTE:
• The front passenger seats have a track memory, which

returns the seat to its original position.

• The recline strap and easy entry lever should not be used

during the automatic returning of the seat to its sitting

position.

Easy Entry Lever

GETTING TO KNOW YOUR VEHICLE

60/40 Split Folding Rear Seat — Four Door Models

To provide additional storage area, each rear seat can be

folded flat to allow for extended cargo space.

NOTE:
• Prior to folding the rear seat, it may be necessary to

reposition the front seat to its mid-track position.

• Be sure that the front seats are fully upright and posi-

tioned forward. This will allow the rear seat to fold

down easily.

• The center head restraints must be in the lowest position

to avoid contact with the center console when folding

the seat.

WARNING!

• It is extremely dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.

• Do not allow people to ride in any area of your

vehicle that is not equipped with seats and seat belts.

• Be sure everyone in your vehicle is in a seat and

using a seat belt properly.

To Fold Down The Rear Seat

There are two release levers located on each upper out-

board side of the rear seat. The larger of the two release

levers folds down the seat and the head restraint simulta-

neously. The smaller lever folds down the head restraint

independently for improved visibility.
To fold the seat, lift upward on the large release lever and

slowly fold down the seatback. The head restraint will fold

automatically with the seat when this lever is pulled.

Seatback Release Lever

GETTING TO KNOW YOUR VEHICLE

NOTE:

You may experience deformation in the seat cush-

ion from the seat belt buckles if the seats are left folded for

an extended period of time. This is normal. By simply

opening the seats to the open position, the seat cushion will

return to its normal shape over time.

To Raise The Rear Seat

Raise the seatback and lock it into place. Then, raise the

head restraint until it locks into place. If interference from

the cargo area prevents the seatback from fully locking,

you will have difficulty returning the seat to its proper

position.

WARNING!

Be certain that the seatback is securely locked into
position. If the seatback is not securely locked into
position the seat will not provide the proper stability
for child seats and/or passengers. An improperly
latched seat could cause serious injury.

Fold And Tumble Rear Seat — Two Door Models

NOTE:
• Prior to folding the rear seat, it may be necessary to

reposition the front seats.

• Be sure that the front seats are fully upright and posi-

tioned forward. This will allow the rear seat to fold

down easily.

Folding The Rear Seat

1. Lift the seatback release lever and fold the seatback

forward.

Rear Seatback Release Lever

GETTING TO KNOW YOUR VEHICLE

2. Slowly flip the entire seat forward.

Using The Retention Straps

1. There are two retention straps located on the back of the

rear seat and two corresponding wire loops located on

the back of each b-pillar. Open the velcro on the strap

and thread through the wire loop. Fold the velcro over

to keep the seat in the folded position. This should be

done on both sides.

2. To return the seat to its normal upright position, reverse

these steps.

Removing The Rear Seat

1. Push down on the release bar on each side, and pull the

seat out and away from the lower bracket.

2. Remove the seat from the vehicle.
3. To reinstall the rear seat, just reverse these steps.

NOTE:

Do not drive the vehicle without reattaching the

rear seat latches.

Rear Seat Tumble Position Retention Strap

Release Bar Location

GETTING TO KNOW YOUR VEHICLE

WARNING!

• It is extremely dangerous to ride in a cargo area,

inside or outside of a vehicle. In a collision, people
riding in these areas are more likely to be seriously
injured or killed.

• Do not allow people to ride in any area of your

vehicle that is not equipped with seats and seat belts.

• Be sure everyone in your vehicle is in a seat and

using a seat belt properly.

• In a collision, you or others in your vehicle could be

injured if seats are not properly latched to their floor
attachments. Always be sure that the seats are fully
latched.

Rear Seat Armrest — If Equipped

The center part of the rear seat can also be used as a rear

armrest with cupholders. To unfold it, grab the pull strap

under the head restraint and pull it forward.

NOTE:

The cupholder liner can be removed for cleaning.

WARNING!

Rear Seat Armrest

GETTING TO KNOW YOUR VEHICLE

HEAD RESTRAINTS

Head restraints are designed to reduce the risk of injury by

restricting head movement in the event of a rear impact.

Head restraints should be adjusted so that the top of the

head restraint is located above the top of your ear.

WARNING!

• All occupants, including the driver, should not oper-

ate a vehicle or sit in a vehicle’s seat until the head
restraints are placed in their proper positions in
order to minimize the risk of neck injury in the event
of a crash.

• Head restraints should never be adjusted while the

vehicle is in motion. Driving a vehicle with the head
restraints improperly adjusted or removed could
cause serious injury or death in the event of a
collision.

Front Head Restraints

To raise the head restraint, pull upward on the head

restraint. To lower the head restraint, push the adjustment

button located on the base of the head restraint, and push

downward on the head restraint. The release button does

not need to be pushed to adjust the head restraint.

To remove the head restraint, raise it as far as it can go then

push the adjustment button and the release button at the

base of each post while pulling the head restraint up. To

reinstall the head restraint, put the head restraint posts into

the holes and push downward. Then adjust it to the

appropriate height.

Front Head Restraint

1 — Release Button
2 — Adjustment Button

GETTING TO KNOW YOUR VEHICLE

Jeep Wrangler (2018 year). Instruction - part 3
