Jeep Wrangler JK (2018 year). Instruction

KEY FOB

Your vehicle uses a key start ignition system. The ignition
system consists of a Remote Keyless Entry (RKE) key fob
with an ignition switch.

Key Fob

The key fob allows you to lock or unlock the doors and
liftgate from distances up to approximately 66 ft (20 m)
using a handheld key fob. The key fob does not need to be
pointed at the vehicle to activate the system.

NOTE:

In the ON/RUN position, the lock button is dis-

abled. Only the unlock button is enabled.

Key Fob

1 — Remote Start Button — If Equipped
2 — Lock Button
3 — PANIC Button
4 — Unlock Button

GETTING TO KNOW YOUR VEHICLE

To Unlock The Doors And Swing Gate

Push and release the key fob unlock button once to unlock
the driver’s door only, or twice to unlock all the doors and
swing gate. When the key fob unlock button is pushed, the
Illuminated Entry will initiate, and the turn signal lights
will flash twice.

To Lock The Doors And Swing Gate

Push and release the lock button on the key fob to lock all
doors. The turn signals will flash, and the horn will chirp
once to acknowledge the lock signal.

Key Fob Battery Replacement

The recommended replacement battery is CR2032.

NOTE:

Perchlorate Material – special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate .

1. With the key fob buttons facing down, use a flat blade

screwdriver to pry the two halves of the key fob apart.
Use extreme care not to damage the seal or internal
components.

2. Remove and replace the battery. Avoid touching the new

battery with your fingers. Skin oils may cause battery
deterioration. If you touch a battery, clean it with
rubbing alcohol.

3. To reassemble the key fob case, snap the two halves

together.

Programming Additional Key Fobs

If you do not have a programmed key fob, contact your
authorized dealer for details.

Separating Key Fob Halves

GETTING TO KNOW YOUR VEHICLE

Refer to “Sentry Key” in “Getting To Know Your Vehicle”
for further information.

General Information

The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

IGNITION SWITCH

Ignition Key Removal

1. Place the gear selector in PARK (if equipped with an

automatic transmission).

2. Turn the ignition switch to the ACC (Accessory) posi-

tion.

3. Push the key and cylinder inward and rotate the key to

the LOCK position.

4. Remove the key from the ignition switch lock cylinder.

Ignition Switch Positions

1 — LOCK
2 — ACC (ACCESSORY)
3 — ON/RUN
4 — START

GETTING TO KNOW YOUR VEHICLE

WARNING!

• Before exiting a vehicle, always shift the automatic

transmission into PARK or the manual transmission
into FIRST gear or REVERSE, apply the parking
brake, then turn the engine OFF, remove the key fob
from the vehicle and lock your vehicle.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle, or in

a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.

• Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves. Al-
ways remove key fob from the vehicle and lock all
doors when leaving the vehicle unattended.

REMOTE STARTING SYSTEM — IF EQUIPPED

This system uses the key fob to start the engine conve-
niently from outside the vehicle while still maintaining
security. The system has a range of approximately 300 ft (91
m).

NOTE:
• The vehicle must be equipped with an automatic trans-

mission to be equipped with Remote Start.

• Obstructions between the vehicle and key fob may

reduce this range.

How To Use Remote Start

All of the following conditions must be met before the
engine will remote start:
• Gear selector in PARK
• Doors closed
• Hood closed

GETTING TO KNOW YOUR VEHICLE

• Hazard switch off
• Brake switch inactive (brake pedal not pushed)
• Ignition key removed from ignition
• Battery at an acceptable charge level
• PANIC button not pushed
• System not disabled from previous remote start event
• Vehicle security alarm not active

WARNING!

• Do not start or run an engine in a closed garage or

confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.

• Keep key fobs away from children. Operation of the

Remote Start System, windows, door locks or other
controls could cause serious injury or death.

Remote Start Abort Message

The following messages will display in the instrument
cluster display if the vehicle fails to remote start or exits
remote start prematurely:

• Remote Start Aborted — Door Open
• Remote Start Aborted — Hood Open
• Remote Start Aborted — Fuel Low
• Remote Start Aborted — Swing Gate Open
• Remote Start Aborted — System Fault
The instrument cluster display message stays active until
the ignition is turned to the ON/RUN position.

To Enter Remote Start

Push and release the remote start button on the key fob
twice within five seconds. The vehicle doors will lock, the
parking lights will flash and the horn will chirp twice (if
programmed). Then, the engine will start and the vehicle
will remain in the remote start mode for a 15-minute cycle.

NOTE:
• The park lamps will turn on and remain on during

remote start mode.

• For security, power window operation is disabled when

the vehicle is in the remote start mode.

GETTING TO KNOW YOUR VEHICLE

• The engine can be started two consecutive times (two

15-minute cycles) with the key fob. However, the igni-
tion switch must be cycled to the ON/RUN position
before you can repeat the start sequence for a third cycle.

Remote start will also cancel if any of the following occur:
• The engine stalls or RPM exceeds 2500.
• Any engine warning lamps come on.
• The hood is opened.
• The hazard switch is pushed.
• The transmission is moved out of PARK.
• The brake pedal is pushed.

To Exit Remote Start Mode Without Driving The
Vehicle

Push and release the remote start button one time or allow
the engine to run for the entire 15-minute cycle.

NOTE:

To avoid unintentional shut downs, the system will

disable the one time push of the remote start button for two
seconds after receiving a valid remote start request.

To Exit Remote Start Mode And Drive The Vehicle

Before the end of the 15-minute cycle, push and release the
unlock button on the key fob to unlock the doors and
disarm the vehicle security alarm (if equipped). Then,
insert the key into the ignition and place the ignition in the
ON/RUN position.

NOTE:

The ignition must be placed in the ON/RUN

position in order to drive the vehicle.

General Information

The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

GETTING TO KNOW YOUR VEHICLE

SENTRY KEY

The Sentry Key Immobilizer System prevents unauthor-
ized vehicle operation by disabling the engine. The system
does not need to be armed or activated. Operation is
automatic, regardless of whether the vehicle is locked or
unlocked.

The system uses key fobs that have an embedded electronic
chip (transponder) to prevent unauthorized vehicle opera-
tion. Therefore, only key fobs that are programmed to the
vehicle can be used to start and operate the vehicle. The
system will shut the engine off in two seconds if someone
uses an invalid key to try to start the engine.

NOTE:

A key fob that has not been programmed is also

considered an invalid key, even if it is cut to fit the ignition
or lock cylinder for that vehicle.

During normal operation, after placing the ignition in the
on position, the vehicle security light will turn on for three
seconds for a bulb check. If the light remains on after the
bulb check, it indicates that there is a problem with the
electronics. In addition, if the vehicle security light begins
to flash after the bulb check, it indicates that someone used
an invalid key to try to start the engine. Either of these
conditions will result in the engine being shut off after two
seconds.

If the vehicle security light turns on during normal vehicle
operation (vehicle running for longer than ten seconds), it
indicates that there is a fault in the electronics. Should this
occur, have the vehicle serviced as soon as possible by an
authorized dealer.

CAUTION!

The Sentry Key Immobilizer system is not compatible
with some aftermarket remote starting systems. Use of
these systems may result in vehicle starting problems
and loss of security protection.

All of the key fobs provided with your new vehicle have
been programmed to the vehicle electronics.

Replacement Key Fobs

NOTE:

Only key fobs that are programmed to the vehicle

electronics can be used to start and operate the vehicle.
Once a key fob is programmed to a vehicle, it cannot be
programmed to any other vehicle.

CAUTION!

Always remove the Sentry Keys from the vehicle and
lock all doors when leaving the vehicle unattended.

GETTING TO KNOW YOUR VEHICLE

Duplication of key fobs may be performed at an authorized
dealer or by following the customer key programming
procedure. This procedure consists of programming a
blank key fob to the vehicle electronics. A blank key fob is
one that has never been programmed.

NOTE:

When having the Sentry Key Immobilizer System

serviced, bring all vehicle key fobs with you to an autho-
rized dealer.

Customer Key Programming

If you have two valid key fobs, you can program new key
fobs to the Sentry Key Immobilizer system by performing
the following procedure:

1. Cut the additional key(s) to match the ignition and lock

cylinder key code.

2. Insert the first valid key into the ignition. Place the

ignition in the ON/RUN position for at least three
seconds, but no longer than 15 seconds. Then, place the
ignition in the LOCK position and remove the first key.

3. Insert the second valid key into the ignition. Place the

ignition in the ON/RUN position within 15 seconds.
After 10 seconds, a chime will sound. In addition, the

Vehicle Security Light will begin to flash. Place the
ignition in the LOCK position and remove the second
key.

4. Insert a blank key into the ignition. Place the ignition in

the ON/RUN position within 60 seconds. After 10
seconds, a single chime will sound. In addition, the
Vehicle Security Light will stop flashing. To indicate that
programming is complete, the Vehicle Security Light
will turn on again for three seconds and then turn off.

The new key is programmed. The key fob will also be
programmed during this procedure.

Repeat this procedure to program up to eight keys. If you
do not have a programmed key fob, contact your autho-
rized dealer for details.

NOTE:

If a programmed key fob is lost, see your autho-

rized dealer to have all remaining key fobs erased from the
system’s memory. This will prevent the lost key from
starting your vehicle. The remaining key fobs must then be
reprogrammed. All vehicle key fobs must be taken to an
authorized dealer at the time of service to be repro-
grammed.

GETTING TO KNOW YOUR VEHICLE

General Information

The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:

This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-
tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the
user’s authority to operate the equipment.

VEHICLE SECURITY ALARM — IF EQUIPPED

The vehicle security alarm monitors the vehicle doors,
swing gate, and ignition for unauthorized operation. While
the vehicle security alarm is armed, interior switches for
door locks are disabled. The vehicle security alarm pro-
vides both audible and visible signals when alarming. The

horn will sound, the headlights will turn on, the park
lamps and/or turn signals will flash repeatedly for three
minutes. If the disturbance is still present (driver’s door,
passenger door, other doors, ignition) after three minutes,
the headlights, park lamps and/or turn signals will flash
for an additional 15 minutes.

NOTE:

The Panic Alarm and the vehicle security alarm are

quite different. Please take a moment to activate the Panic
Alarm and the vehicle security alarm to hear the differ-
ences in the horn. In case one should go off in the future,
you will need to know which mode has been activated in
order to deactivate it.

Rearming The System

If something triggers the alarm, and no action is taken to
disarm it, the vehicle security alarm will turn off the horn
after three minutes, turn off all of the visual signals after 15
minutes, and then the vehicle security alarm will rearm
itself.

GETTING TO KNOW YOUR VEHICLE

To Arm The System

The vehicle security alarm will set when you use the
Remote Keyless Entry key fob to lock the doors and swing
gate, or when you use the power door lock switch while
the door is open. After all the doors are locked and closed,
the vehicle security light (located on the instrument cluster)
will flash rapidly for about 16 seconds to signal that the
vehicle security alarm is arming. During this 16-second
arming period, opening any door or the swing gate will
cancel the arming. If the vehicle security alarm is success-
fully set, the vehicle security light will flash at a slower rate
to indicate the vehicle security alarm is armed.

To Disarm The System

To disarm the vehicle security alarm, you will need to push
the unlock button on the key fob, or turn the ignition
switch to the ON/RUN position. If something has trig-
gered the vehicle security alarm in your absence, the horn
will sound three times, and the exterior lights blink three
times when you unlock the doors. Check the vehicle for
tampering.

The vehicle security alarm is designed to protect your
vehicle; however, you can create conditions where the
vehicle security alarm will arm unexpectedly. If you remain
in the vehicle and lock the doors with the key fob, once the

vehicle security alarm is armed (after 16 seconds), when
you pull the door handle to exit, the alarm will sound. If
this occurs, push the unlock button on the key fob to
disarm the vehicle security alarm. You may also acciden-
tally disarm the vehicle security alarm by unlocking the
driver’s door with the key and then locking it. The door
will be locked but the vehicle security alarm will not arm.

NOTE:
• Unlocking the doors with the manual door lock plung-

ers or the driver’s door lock cylinder will not disarm the
vehicle security alarm.

• When the vehicle security alarm is armed, the interior

power door lock switches will not unlock the doors.

DOORS

CAUTION!

Careless handling and storage of the removable door
panels may damage the seals, causing water to leak
into the vehicle’s interior.

GETTING TO KNOW YOUR VEHICLE

Manual Door Locks

All doors are equipped with an interior rocker-type door
lock lever. To lock a door when leaving your vehicle, push
the rocker lever forward to the lock position and close the
door. To unlock the door, push the rocker lever rearward.

NOTE:

The ignition key that is used to start the vehicle is

used to lock or unlock the doors, swing gate, glove
compartment, and console storage.

WARNING!

• For personal security reasons and safety in a colli-

sion, lock the vehicle doors when you drive, as well
as when you park and exit the vehicle.

(Continued)

Manual Door Lock (Full Frame Doors)

Manual Door Lock (Half Doors)

GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

• When exiting the vehicle, always remove the key

from the ignition and lock your vehicle. Unsuper-
vised use of vehicle equipment may cause severe
personal injuries and death.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle or in

a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.

Power Door Locks — If Equipped

The power door lock switch is located on each front door
panel. Push the switch forward to lock the doors, and
rearward to unlock the doors.

WARNING!

• For personal security reasons and safety in a colli-

sion, lock the vehicle doors when you drive, as well
as when you park and exit the vehicle.

• When exiting the vehicle, always remove the key

from the ignition and lock your vehicle. Unsuper-
vised use of vehicle equipment may cause severe
personal injuries and death.

(Continued)

Power Door Lock Switch

GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle or in

a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.

Child-Protection Door Lock System — Rear Doors

To provide a safer environment for small children riding in
the rear seats, the rear doors are equipped with Child-
Protection Door Lock system.

To Engage Or Disengage The Child-Protection Door Lock
System

1. Open the rear door.

2. Insert the tip of the ignition key into the lock and rotate

to the lock or unlock position.

3. Repeat steps one and two for the opposite rear door.

WARNING!

Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened from
the outside when the Child-Protection locks are en-
gaged (locked).

NOTE:

For emergency exit with the system engaged, move

the rocker lever rearward (unlocked position), roll down
the window and open the door with the outside door
handle.

Child Protection Door Lock Function

GETTING TO KNOW YOUR VEHICLE

Upper Half Door Window Removal — If Equipped

Grasp the half door window and pull upward.

Upper Half Door Window Installation — If
Equipped

1. Grasp the half door window and line up the pins with

the pockets in the lower door.

2. Push down to ensure the half door window is fully

seated.

Front Door Removal

WARNING!

Do not drive your vehicle on public roads with the
doors removed as you will lose the protection they can
provide. This procedure is furnished for use during
off-road operation only.

NOTE: Hinge pin can break if overtightened during door
reinstall (Max Torque: 10 N·m / 7.5 ft· lb).

Upper Half Door Window

Door Removal Warning Label

GETTING TO KNOW YOUR VEHICLE

1. Roll down the glass window to prevent any damage.

2. Remove the hinge pin screws from the upper and lower

outside hinges (using a #T50 Torx head driver).

NOTE:

The hinge pin screws and nuts can be stowed in

the rear cargo tray located under the rear loadfloor.

3. Unplug the wiring harness connector under the instru-

ment panel by pushing the tab at the base of the
connector and pulling down to disconnect.

Hinge Pin Screw

Door Strap/Harness Location

1 — Wiring Harness (follow the harness up and under the instru-
ment panel to the connector)
2 — Body Hook
3 — Door/Harness Strap

GETTING TO KNOW YOUR VEHICLE

4. Unhook the door strap from the body hook. Be careful

not to allow the door to swing fully open as the mirror
may damage the paint.

5. With the door open, lift the door to clear the hinge pins

from their hinges and remove the door.

NOTE:

Doors are heavy; use caution when removing

them.

To reinstall the door(s), perform the previous steps in the
opposite order.

Rear Door Removal (Four-Door Models)

WARNING!

Do not drive your vehicle on public roads with the
doors removed as you will lose the protection they can
provide. This procedure is furnished for use during
off-road operation only.

NOTE: Hinge pin can break if overtightened during door
reinstall (Max Torque: 10 N·m / 7.5 ft· lb).

1. Roll down the glass window to prevent any damage.

2. Remove the hinge pin screws from the upper and lower

outside hinges (using a #T50 Torx head driver).

NOTE:

The hinge pin screws and nuts can be stowed in the

rear cargo tray located under the rear load floor.

Door Removal Warning Label

GETTING TO KNOW YOUR VEHICLE

Jeep Wrangler JK (2018 year). Instruction - part 2
