Jeep Compass (2019 year). Instruction

Audio

After pressing the “Audio” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Equalizer

Bass

Mid

Treble

NOTE:
When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and
“–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the
touchscreen. Bass/Mid/Treble also allow you to simply slide your finger up or down to change the setting as well as
press directly on the desired setting.

Balance/Fade

Up Arrow

Button

Down Ar-

row Button

Left Arrow

Button

Right

Arrow

Button

Center “C”

Button

NOTE:
When in this display you may adjust the “Balance/Fade” of the audio by using the “Arrow” button on the touch-
screen to adjust the sound level from the front and rear or right and left side speakers. Press the “Center ‘C’ Button”
on the touchscreen to reset the balance and fade to the factory setting.

468

MULTIMEDIA

Setting Name

Selectable Options

Speed Adjusted Volume

Off

Surround Sound — If Equipped

Off

Loudness

Off

NOTE:
The “Loudness” feature improves sound quality at lower volumes when enabled.

AUX Volume Offset — If Equipped

NOTE:
The “AUX Volume Offset” feature provides the ability to tune the audio level for portable devices connected through
the AUX input.

Phone/Bluetooth

After pressing the “Phone/Bluetooth” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Paired Phones

List of Paired Phones

NOTE:
This feature shows which phones are paired to the Phone/Bluetooth system. For further information, refer to the
Uconnect Owner’s Manual Supplement.

MULTIMEDIA

469

SiriusXM Setup — If Equipped

After pressing the “SiriusXM Setup” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Channel Skip

List of Channels

NOTE:
SiriusXM can be programmed to designate a group of channels that are the most desirable to listen to or to exclude
undesirable channels while scanning. This feature allows you to select the channels you would like to skip.

Subscription Info

Sirius ID

NOTE:
New vehicle purchasers or lessees will receive a free limited time subscription to SiriusXM Satellite Radio with your
radio. Following the expiration of the free services, it will be necessary to access the information on the Subscription
Information screen to re-subscribe.

1. Press the “Subscription Info” button on the touchscreen to access the Subscription Information screen.

2. Write down the Sirius ID numbers for your receiver. To reactivate your service, either call the number listed on the

screen or visit the provider online.

470

MULTIMEDIA

Restore Settings

After pressing the “Restore Settings” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Restore Settings

Cancel

NOTE:
When the “Restore Settings” feature is selected, it will reset all of the audio settings to their default settings.

Clear Personal Data

After pressing the “Clear Personal Data” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Clear Personal Data

Cancel

NOTE:
When the “Clear Personal Data” feature is selected it will remove all personal data including Bluetooth devices and
presets.

MULTIMEDIA

471

Customer Programmable Features — Uconnect 4
Settings

Press the “Settings” button on the bottom bar, or press the
“Apps

” button, then press the “Settings” button on

the touchscreen to display the menu setting screen. In
this mode the Uconnect system allows you to access all
of the available programmable features.

NOTE:
• Only one touchscreen area may be selected at a time.
• Depending on the vehicle’s options, feature settings may

vary.

When making a selection, press the button on the touch-
screen to enter the desired mode. Once in the desired
mode, press and release the preferred setting “option” until
a check-mark appears next to the setting, showing that
setting has been selected. Once the setting is complete,
press the “X” button on the touchscreen to close out of the
settings screen. Pressing the Up or Down Arrow button on
the right side of the screen will allow you to toggle up or
down through the available settings.

The following tables list the settings that may be found
within the Uconnect 4 with 7-inch display radio, along
with the selectable options pertaining to each setting.

Uconnect 4 With 7-inch Display Buttons On The

Touchscreen And Buttons On The Faceplate

1 — Uconnect Buttons On The Touchscreen
2 — Uconnect Buttons On The Faceplate

472

MULTIMEDIA

Language

After pressing the “Language” button on the touchscreen,
the following settings will be available:

Setting Name

Selectable Options

Language

English

Espanol

Francais

Display

After pressing the “Display” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Display Mode

Auto

Manual

Display Brightness Headlights On

Display Brightness Headlights Off

AutoShow

Off

Touchscreen Beep

Off

Control Screen Timeout — If

Equipped

Off

Phone Pop-ups Displayed in Cluster

— If Equipped

Off

MULTIMEDIA

473

Units

After pressing the “Units” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Units

Metric

Custom

NOTE:

• The “Metric” option changes the instrument cluster display to metric units of measure.

• The “Custom” option allows setting the “Distance, Fuel Consumption” (MPG (US), MPG(UK), L/100km, or

km/L),“Pressure” (kPa, or bar) and “Temperature” (C, or F) units of measure independently.

Voice

After pressing the “Voice” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Always

With Help

Never

474

MULTIMEDIA

Time & Date

After pressing the “Time & Date” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Set Time Hours

NOTE:
The “Set Time Hours” feature will allow you to adjust the hours.

Set Time Minutes

NOTE:
The “Set Time Minutes” feature will allow you to adjust the minutes.

Time Format

12hrs

24hrs

Set Date

Up Arrow

Down Arrow

NOTE:
Within the “Set Date” setting, press the corresponding arrow buttons on the touchscreen to adjust to the correct date.

Show Time Status — If Equipped

Off

Sync Time With GPS — If Equipped

Off

MULTIMEDIA

475

Safety/Driving Assistance — If Equipped

After pressing the “Safety/Driving Assistance” button on
the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Forward Collision Warning

Off

Warning Only

Warning + Active

Braking

NOTE:
The “Forward Collision Warning Plus (FCW+)” setting includes Advanced Brake Assist (ABA). The ABA applies ad-
ditional brake pressure when the driver requests insufficient brake pressure to avoid a potential frontal collision.
When the “Warning Only” option is selected a chime will sound alerting you of a possible collision with the vehicle
in front of you and more brake pressure is needed. When the “Warning + Active Braking” option is selected, it will
apply the brakes to slow your vehicle in case of potential forward collision and sound an audible chime to alert you.

Forward Collision Warning Sensitivity — If Equipped

Near

Medium

Far

NOTE:
The “Forward Collision Warning Plus (FCW+) Sensitivity” setting determines at what relative distance the vehicle
directly in front of you needs to be at, before the system will warn you of a possible collision with the vehicle directly
in front of you, based on the option is selected. “Far” will give you the most amount of reaction time, whereas
“Near” will give you the least amount of reaction time, based on the distance between the two vehicles.

LaneSense Warning — If Equipped

Early

Medium

Late

NOTE:
The “LaneSense Warning” setting determines at what distance the LaneSense system will warn you, through steering
wheel feedback, of a possible lane departure.

476

MULTIMEDIA

Setting Name

Selectable Options

LaneSense Strength — If Equipped

Low

Med

High

ParkSense — If Equipped

Sound

Sound and Display

Rear ParkSense Volume

Low

Medium

High

Blind Spot Alert — If Equipped

Off

Lights

Lights and

Chime

NOTE:
If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged,
the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor alignment. A sen-
sor that is misaligned will result in the Blind Spot Monitor (BSM) not operating to specification.

ParkView Backup Camera Delay

Off

NOTE:
The “ParkView Backup Camera Delay” setting determines whether or not the screen will display the rear view image
with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE. This delay will be canceled
if the vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to
the OFF position.

ParkView Backup Camera Active Guidelines

Off

Rain Sensing Auto Wipers

Off

MULTIMEDIA

477

Brakes

After pressing the “Brakes” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Auto Park Brake

Off

Brake Service — If Equipped

Yes

NOTE:
Selecting the “Brake Service” feature will display a pop-up asking whether you would like to retract the park brakes
to allow brake system service.

Lights

After pressing the “Lights” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Interior Ambient Lights

NOTE:
The “Interior Ambient Lights” setting can also be adjusted by selecting any point on the scale between the “+” and
“-” buttons on the touchscreen.

478

MULTIMEDIA

Setting Name

Selectable Options

Headlight Sensitivity — If

Equipped

Level 1: minimum

sensitivity

Level 2: medium sen-

sitivity

Level 3: maximum sensitivity

NOTE:
The greater the sensitivity set, the less the external light variation required to turn on the lights (e.g. with a setting on
level 3 at sunset the headlights turn on earlier than in levels 1 and 2).

Headlight Off Delay

NOTE:
When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights
remain on after the engine is shut off.

Greeting Lights

Off

Daytime Running Lights

Off

Auto Dim High Beams — If

Equipped

Off

Cornering Lights

Off

NOTE:
When the “Cornering Lights” feature is selected, if the steering wheel rotation angle is large or the turn signal indica-
tors are on, a light (incorporated in the fog light) will turn on, on the relevant side to improve visibility at night.

Flash Lights With Lock — If

Equipped

Off

MULTIMEDIA

479

Doors & Locks

After pressing the “Doors & Locks” button on the touch-
screen, the following settings will be available:

Setting Name

Selectable Options

Auto Unlock On Exit

Off

NOTE:
When this feature is selected, all doors will unlock when the vehicle is stopped and the transmission is in the PARK
or NEUTRAL position and the driver’s door is opened.

Flash Lights With Lock

Off

Remote Door Unlock

Driver Door

All Doors

Setting Name

Selectable Options

Auto Door Locks — If Equipped

Off

NOTE:
When this feature is selected, all doors will lock automatically when the vehicle reaches a speed of 12 mph
(20 km/h).

480

MULTIMEDIA

Engine Off Options — If Equipped

After pressing the “Engine Off Options” button on the
touchscreen, the following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

Radio Off Delay

0 min

20 min

Radio Off With Door

Off

Audio

After pressing the “Audio” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Balance & Fade

NOTE:
When in this display you may adjust the “Balance & Fade” of the audio by pressing and dragging the “Speaker Icon”
toward any location in the box.

Equalizer

Bass

Mid

Treble

MULTIMEDIA

481

Setting Name

Selectable Options

Speed Adjusted Volume

Off

Loudness

Off

NOTE:
The “Loudness” feature improves sound quality at lower volumes when enabled.

AUX Volume Offset — If Equipped

NOTE:
This feature provides the ability to tune the audio level for portable devices connected through the AUX input.

Auto Play — If Equipped

Off

NOTE:
The “Auto Play” feature automatically starts playing audio when a USB device is connected and turned on.

Radio Off With Door — If

Equipped

Off

NOTE:
The “Radio Off With Door” feature will keep the radio on until the driver or passenger door is opened, or when the
“Radio Off Delay” selected time has expired.

482

MULTIMEDIA

Phone

After pressing the “Phone” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Do Not Disturb

Do Not Disturb Options

Paired Phones And Audio Devices

List Of Paired Phones And Audio Devices

NOTE:
This feature shows which phones and audio devices are paired to the Phone/Bluetooth system. For further informa-
tion, refer to the Uconnect Owner’s Manual Supplement.
Phone Pop-ups Displayed In Cluster

— If Equipped

Off

MULTIMEDIA

483

Jeep Compass (2019 year). Instruction - part 30
