8Wa-40 INSTRUMENT CLUSTER

Component

Page

Airbag Control Module . . . . . . . . . . . 8Wa-40-6, 7, 8
Brake Warning Pressure Switch . . . . . 8Wa-40-10, 9
Controller Antilock Brake Relay . . . . 8Wa-40-6, 7, 8
Daytime Running Lamp Module . . . . . . . 8Wa-40-14
Driver Door Ajar Switch . . . . . . . . . . . . . 8Wa-40-11
Engine Control Module . . . . . . . . . . . 8Wa-40-16, 17
Engine Coolant Temperature Sensor . . . . . 8Wa-40-4
Engine Coolant Temperature

Sensor No. 2 . . . . . . . . . . . . . . . . . . . . . 8Wa-40-5

Engine Oil Pressure Sensor . . . . . . . . . . 8Wa-40-4, 5
Engine Starter Motor Relay . . . . . . . . . 8Wa-40-7, 8
Fog Lamp Relay . . . . . . . . . . . . . . . . . . 8Wa-40-7, 8
Fog Lamp Relay No. 1 . . . . . . . . . . . . . . . 8Wa-40-14
Fuel Level Sensor . . . . . . . . . . . . . . . . . . . 8Wa-40-3
Fuel Pump Module . . . . . . . . . . . . . . . . . . 8Wa-40-3
Fuse 6 (JB) . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-15
Fuse 9 (JB) . . . . . . . . . . . . . . . . . . . . . 8Wa-40-17, 2
Fuse 12 (JB) . . . . . . . . . . . . . . . . . . . 8Wa-40-12, 13
Fuse 16 (PDC) . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-2
G101 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-9
G106 . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-10, 6, 7, 8
G107 . . . . . . . . . . . . . . . . . . . . . 8Wa-40-12, 13, 6, 7
G108 . . . . . . . . . . . . . . . . . . . . . 8Wa-40-10, 14, 2, 9
G123 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-17
G154 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-17
G302 . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-11, 8

Component

Page

G303 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-11
Headlamp Beam Select Switch . . . . . . . . 8Wa-40-14
Headlamp Switch . . . . . . . . . . . . . . . . 8Wa-40-11, 15
Ignition Switch . . . . . . . . . . . . . . . 8Wa-40-10, 119
Instrument Cluster . 8Wa-40-2, 3, 4, 5, 6, 7, 8, 9, 10,

11, 12, 13, 14, 15, 16

Junction Block . . . . . . . . . . 8Wa-40-2, 12, 13, 15, 17
Liftgate Ajar Switch . . . . . . . . . . . . . . . . 8Wa-40-15
Low Coolant Switch . . . . . . . . . . . . . . . . 8Wa-40-17
Message Center . . . . . . . . . . . . . . . . . . . . 8Wa-40-17
Park Brake Switch . . . . . . . . . . . . . . . 8Wa-40-10, 9
Power Distribution Center . . . . . . . . . . . . 8Wa-40-2
Powertrain Control

Module . . . . . . . . . . . . . . . . 8Wa-40-3, 4, 5, 16, 17

Rear Window Defogger Relay . . . . . . 8Wa-40-12, 13
Rear Window Defogger Switch . . . . . . 8Wa-40-12, 13
Remote Keyless Entry Module . . . . . . 8Wa-40-12, 13
Seat Belt Switch . . . . . . . . . . . . . . . . 8Wa-40-6, 7, 8
Sentry Key Immobilizer Module . . . . 8Wa-40-12, 13
Transfer Case Switch . . . . . . . . . . . . . 8Wa-40-10, 9
Transmission Control Module . . . . . . . . . . 8Wa-40-3
Turn Signal/Hazard Switch . . . . . . . . . . . 8Wa-40-14
Underhood Lamp/Switch . . . . . . . . . . . . . . 8Wa-40-2
Vehicle Speed Sensor . . . . . . . . . . . . . . . . . 8Wa-40-3
Washer Fluid Level Switch . . . . . . . . 8Wa-40-6, 7, 8
Water In Fuel Sensor . . . . . . . . . . . . . . . 8Wa-40-17
