Fig.

42

Engine

and

Battery

Diesel

Engine

8W - 90 - 50

8W - 90 CONNECTOR LOCATIONS

XJ

DESCRIPTION AND OPERATION (Continued)

Fig. 43 Transmission Diesel Engine

XJ

8W - 90 CONNECTOR LOCATIONS

8W - 90 - 51

DESCRIPTION AND OPERATION (Continued)

8W-95 SPLICE LOCATIONS

DESCRIPTION AND OPERATION

INTRODUCTION

This section provides illustrations identifying the

general location of the splices in this vehicle. A splice
index is provided. Use the wiring diagrams in each

section for splice number identification. Refer to the
index for proper splice number.

SPLICE LOCATIONS

For splices that are not shown in the figures in

this section a N/S is placed in the Fig. column.

Splice
Number

Location

Fig.

S100
(Except
Built-Up-
Export)

Near T/O for Right Headlamp

9

S101

Near T/O for Right Headlamp

9

S102

Near T/O for Right Headlamp

9

S103

Near T/O for Left Headlamp

9

S104

Near T/O for Left Headlamp

9

S105

Near T/O for Left Headlamp

9

S106

Near T/O for Left Headlamp

9

S107
(2.5L)

Near T/O for G101

11

S107
(4.0L)

Near T/O for Fuel Injector NO.
6

10

S108
(2.5L)

Near Fuel Injector T/O’s

11

S108
(4.0L)

Near T/O for Ignition Coil Pack

10

S108
(4.0L)
(California/
European
III)

Near Fuel Injector T/O’s

10

S109
(2.5L)

Near Fuel Injector T/O’s

11

S109
(4.0L)

Near Fuel Injector T/O’s

10

S110

Near Fuel Injector T/O’s

11

S111
(2.5L)

Near T/O for G101

11

S111
(4.0L)

Near Fuel Injector T/O’s

10

S112

Near Fuel Injector T/O’s

10

S113
(2.5L)

Near T/O for Fuel Injector
NO. 3

11

Splice
Number

Location

Fig.

S113
(4.0L)

Between Fuel Injector NO. 2
and Fuel Injector NO. 3 T/O’s

10

S114
(2.5L)

Near T/O for Fuel Injector NO.
2

11

S114
(4.0L)

Between Fuel Injector NO. 2
and Fuel Injector NO. 3 T/O’s

10

S115
(2.5L)

Near T/O for Crankshaft
Position Sensor

11

S115
(4.0L)

Near T/O for Idle Air Control
Motor

10

S116
(Built-Up-
Export)

Near T/O for Right Headlamp

9

S118

In T/O for Generator Terminal

N/S

S119
(2.5L)

In T/O for Engine Oil Pressure
Sensor

11

S119
(4.0L)

Near Fuel Injector T/O’s

10

S120
(A/T)
(2.5L)

Near Fuel Injector T/O’s

11

S121

Near Fuel Injector T/O’s

10

S122

Near T/O for Ignition Coil Pack

10

S123
(4.0L)
(California/
European
III)

Near T/O for Powertrain
Control Module - C2

N/S

S124

Near T/O for Electronic
Vacuum Modulator

26, 27

S130
(Diesel)

Near T/O for Power
Distribution Center

24, 25

S130
(Gas)

Near Grommet T/O for
Junction Block - C2

3, 4, 7, 8

S131
(Diesel)
(LHD)

Near T/O for Underhood Lamp

26

XJ

8W - 95 SPLICE LOCATIONS

8W - 95 - 1
