SPLICE NUMBER
LOCATION
FIG.
S327
Near T/O for Left Heated Seat Assembly
N/S
S328
In T/O for Heated Seat Module
N/S
S329
Near T/O for Right Heated Seat Switch
N/S
S331
Under Carpet Near Driver Seat Right Front Fastner
37, 41
S332
Under Carpet Near Driver Seat Right Front Fastner
37, 41
S333
Near Driver Seat Belt Tensioner
36
S334
Below Right B-Pillar
35, 40
S336 (LHD)
Near T/O for Left Instrument Panel
33
S336 (RHD)
Near T/O for Right Instrument Panel Speaker
38
S340 (Base)
Near T/O for C201
33
S341
Near T/O for C201
33, 42
S342 (Base)
Near T/O for Right Instrument Panel Speaker
33
S344 (Base)
Near T/O for Right Instrument Panel Speaker
33
S345
Center Console
37, 41
S346
In T/O for Trailer Tow Relays
50
S347
Near T/O for Right Tail/Stop Lamp
49
S348
Near T/O for Right Tail/Stop Lamp
49
S349
Near T/O for License Lamp
49
S351
In T/O for Rear Window Defogger
51
S352
In T/O for Rear Window Defogger
51
S353
In T/O for Radio C2
N/S
S354
In T/O for CD Changer
46
S355
In T/O for Radio C2
N/S
S356
Near T/O for Center High Mounted Stop Lamp
51
S358
Center Instrument Panel
38
S360
Near T/O for Left Power Mirror
42
S361
Near T/O for Left Power Mirror
42
S363
Left Side Lightbar
53
S364
Near T/O for Left Front Door Speaker
N/S
S369
Left Side Lightbar
53
S370
Near T/O for Right Power Mirror
42
S371
Near T/O for Right Door Lock Switch
42
S372
Lower Front Engine Compartment
23
S373
Right Front Lower Engine Compartment
23
S377 (RHD)
Near T/O for Right Door Lock Switch
42
S378 (RHD)
Near T/O for Right Front Power Window Motor
42
S379 (RHD)
In Rear Body Harness near T/O for C310
N/S
S380
Near T/O for Rear Wiper Motor
51
S381
Near T/O for Tailgate Cylinder Lock Switch
51
S382
Near T/O for License Lamp
51
S390
Near T/O for Intrusion Sensor
N/S
S391
Near T/O for Left Visor/Vanity Lamp
N/S
S392
Near T/O for Left Visor/Vanity Lamp
N/S
8W - 91 - 14
8W-91 CONNECTOR/GROUND/SPLICE LOCATION
KJ
