Jeep Grand Cherokee WK. Manual - part 758





8W-30 FUEL/IGNITION SYSTEM

Component

Page

Assembly-Exhaust Gas Recirculation

Valve . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-11

Assembly-Natural Vacuum Leak

Detection . . . . . . . . . . . . . . . . . . . . . . . 8W-30-17

Assembly-Shift Lever . . . . . . . . . . . . . . . . 8W-30-19
Capacitor-Ignition No. 1 . . . . . . . . . . . . . . . 8W-30-5
Capacitor-Ignition No. 2 . . . . . . . . . . . . . . . 8W-30-5
Cluster . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-15
Coil-Ignition-No. 1 . . . . . . . . . . . . . . . . . . . 8W-30-5
Coil-Ignition-No. 2 . . . . . . . . . . . . . . . . . . . 8W-30-7
Coil-Ignition-No. 3 . . . . . . . . . . . . . . . . . . . 8W-30-5
Coil-Ignition-No. 4 . . . . . . . . . . . . . . . . . . . 8W-30-7
Coil-Ignition-No. 5 . . . . . . . . . . . . . . . . . . . 8W-30-5
Coil-Ignition-No. 6 . . . . . . . . . . . . . . . . . . . 8W-30-7
Coil-Ignition-No. 7 . . . . . . . . . . . . . . . . . . . 8W-30-5
Coil-Ignition-No. 8 . . . . . . . . . . . . . . . . . . . 8W-30-7
Data Link Connector . . . . . . . . . . . . . . . . . 8W-30-2
Diode-Zener No. 2 . . . . . . . . . . . . . . . . . . . 8W-30-15
Fan Module-Condenser Cooling . . . . . . . . 8W-30-20
Fuse 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-4
Fuse 16 . . . . . . . . . . . . . . . . . . . . . . . 8W-30-4, 5, 18
Fuse 20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-3
Fuse 23 . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-20
Fuse 24 . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-2, 14
Fuse 28 . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-4, 6
G100 . . . . . . . . . . . . . . . . . . . . . . . 8W-30-14, 15, 20
G101 . . . . . . . . . . . . . . . . . . . . . . 8W-30-8, 9, 11, 13
G102 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-3
G200 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-18
G302 . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-15, 17
Generator . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-3
Injector-Fuel-No. 1 . . . . . . . . . . . . . . . . . . . 8W-30-6
Injector-Fuel-No. 2 . . . . . . . . . . . . . . . . . . . 8W-30-7
Injector-Fuel-No. 3 . . . . . . . . . . . . . . . . . . . 8W-30-6
Injector-Fuel-No. 4 . . . . . . . . . . . . . . . . . . . 8W-30-7
Injector-Fuel-No. 5 . . . . . . . . . . . . . . . . . . . 8W-30-6
Injector-Fuel-No. 6 . . . . . . . . . . . . . . . . . . . 8W-30-7
Injector-Fuel-No. 7 . . . . . . . . . . . . . . . . . . . 8W-30-6
Injector-Fuel-No. 8 . . . . . . . . . . . . . . . . . . . 8W-30-7
Junction Block . . . . . . . . . . . . . . . . 8W-30-2, 14, 18
Module-Antilock Brakes . . . . . . . . . . . . . . . 8W-30-2
Module-Front Control . . . . . . . . . . . 8W-30-2, 14, 20
Module-Hydraulic Cooling Fan . . . . . . . . . 8W-30-14
Module-Integrated Power . . . . . 8W-30-2, 14, 15, 20

Component

Page

Module-Powertrain Control . . 8W-30-2, 3, 4, 5, 6, 7,

8, 9, 10, 11, 12, 13, 14, 16, 17, 18, 19

Module-Steering Control . . . . . . . . . . . . . . 8W-30-18
Motor-Fuel Pump . . . . . . . . . . . . . . . . . . . 8W-30-15
Motor-Iac . . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-17
Power Distribution Center . . . . 8W-30-3, 4, 5, 6, 14
Relay-A/C Clutch . . . . . . . . . . . . . . . . . . . 8W-30-18
Relay-Auto Shut Down . . . . . . . . . . . . . . . . 8W-30-4
Relay-Fuel Pump . . . . . . . . . . . . . . . . 8W-30-14, 15
Relay-Radiator Fan High . . . . . . . . . . . . . 8W-30-20
Relay-Radiator Fan Low . . . . . . . . . . . . . . 8W-30-20
Relay-Starter Motor . . . . . . . . . . . . . . . . . 8W-30-17
Sensor-Accelerator Pedal Position . . . . . . 8W-30-10
Sensor-Camshaft Position . . . . . . . . . . . . . 8W-30-11
Sensor-Crankshaft Position . . . . . . . . . . . 8W-30-12
Sensor-Engine Coolant Temperature . . . . 8W-30-16
Sensor-Intake Air Temperature . . . . . . . . 8W-30-16
Sensor-Knock . . . . . . . . . . . . . . . . . . . . . . 8W-30-16
Sensor-Knock No. 1 . . . . . . . . . . . . . . . . . 8W-30-16
Sensor-Knock No. 2 . . . . . . . . . . . . . . . . . 8W-30-16
Sensor-Line Pressure . . . . . . . . . . . . . . . . 8W-30-11
Sensor-Map . . . . . . . . . . . . . . . . . . . . . . . . 8W-30-11
Sensor-Oil Pressure . . . . . . . . . . . . . . . . . 8W-30-10
Sensor-Oil Temperature . . . . . . . . . . . . . . 8W-30-10
Sensor-Oxygen-Left Front . . . . . . . . . . . . . 8W-30-9
Sensor-Oxygen-Left Rear . . . . . . . . . . . . . . 8W-30-8
Sensor-Oxygen-Right Front . . . . . . . . . . . . 8W-30-9
Sensor-Oxygen-Right Rear . . . . . . . . . . . . . 8W-30-8
Sensor-Throttle Position . . . . . . . . . . . . . . 8W-30-12
Servo-Speed Control . . . . . . . . . . . . . . . . . 8W-30-18
Solenoid-EVAP/Purge . . . . . . . . . . . . . . . . 8W-30-19
Solenoid-Multi Displacement

System Cyl 1 . . . . . . . . . . . . . . . . . . . . 8W-30-13

Solenoid-Multi Displacement

System Cyl 4 . . . . . . . . . . . . . . . . . . . . 8W-30-13

Solenoid-Multi Displacement

System Cyl 6 . . . . . . . . . . . . . . . . . . . . 8W-30-13

Solenoid-Multi Displacement

System Cyl 7 . . . . . . . . . . . . . . . . . . . . 8W-30-13

Switch-Ignition . . . . . . . . . . . . . . . . . . . . . . 8W-30-3
Switch-Oil Pressure . . . . . . . . . . . . . . . . . . 8W-30-3
Switch-Stop Lamp . . . . . . . . . . . . . . . . . . 8W-30-19
Throttle Body . . . . . . . . . . . . . . . . . . . . . . 8W-30-12

WK

8W-30 FUEL/IGNITION SYSTEM

8W - 30 - 1
