2001 JEEP GRAND CHEROKEE

2001 JEEP GRAND CHEROKEE

8Wa-40 INSTRUMENT CLUSTER

Component

Page

Airbag Control Module . . . . . . . . . . . . . 8Wa-40-4, 5
Airbag Warning Indicator . . . . . . . . . . . . . 8Wa-40-5
Body Control Module . . . . . . . . 8Wa-40-4, 5, 6, 7, 10
Combination Flasher . . . . . . . . . . . . . . . . . 8Wa-40-3
Controller Antilock Brake . . . 8Wa-40-4, 5, 6, 7, 8, 9
Cruise Indicator . . . . . . . . . . . . . . . . . . . . 8Wa-40-5
Data Link Connector . . . . . . . . . . . . . . . 8Wa-40-4, 5
Diagnostic Junction Port . 8Wa-40-4, 5, 6, 7, 8, 9, 10
Engine Control Module . . . . . . . . . . . . . . . 8Wa-40-9
Fuse 17 (JB) . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-2
Fuse 22 (JB) . . . . . . . . . . . . . . . . . . . . . 8Wa-40-2, 3
G104 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-3
G200 . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-2, 3

Component

Page

G300 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-10
G301 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Wa-40-10
Instrument Cluster . 8Wa-40-2, 3, 4, 5, 6, 7, 8, 9, 10
Junction Block . . . . . . . . . . . . . 8Wa-40-2, 3, 8, 9, 10
Low Coolant Level Indicator . . . . . . . . . . . 8Wa-40-5
Park Brake Switch . . . . . . . . . . . . . . . . 8Wa-40-6, 7
Powertrain Control Module . . . . . . . 8Wa-40-4, 5, 6,

7, 8, 9, 10

Seat Belt Switch . . . . . . . . . . . . . . . . . . . 8Wa-40-10
Transfer Case Switch . . . . . . . . . . . . . . . . 8Wa-40-3
Transmission Control Module . . . . . . 8Wa-40-4, 5, 8
Transmission Temperature Indicator . . . . . 8Wa-40-5
Vehicle Information Center . . . . . . . . . . . . 8Wa-40-7

WJ

8Wa-40 INSTRUMENT CLUSTER

8Wa - 40 - 1

2001 JEEP GRAND CHEROKEE

2001 JEEP GRAND CHEROKEE
