ward mounting screw and the roof panel above the
overhead console. Equivalent units must be rated as
continuous duty for 110/115 volts and 60 Hz. They
must also have a field strength of over 350 gauss at 7
millimeters (0.25 inch) beyond the tip of the probe.

To demagnetize the roof panel and the overhead

console forward mounting screw, proceed as follows:

(1) Be certain that the ignition switch is in the Off

position, before you begin the demagnetizing proce-
dure.

(2) Connect the degaussing tool to an electrical

outlet, while keeping the tool at least 61 centimeters
(2 feet) away from the compass unit.

(3) Slowly approach the head of the overhead con-

sole forward mounting screw with the degaussing
tool connected.

(4) Contact the head of the screw with the plastic

coated tip of the degaussing tool for about two sec-
onds.

(5) With the degaussing tool still energized, slowly

back it away from the screw. When the tip of the tool
is at least 61 centimeters (2 feet) from the screw
head, disconnect the tool.

(6) Place a piece of paper approximately 22 by 28

centimeters (8.5 by 11 inches), oriented on the vehicle
lengthwise from front to rear, on the center line of
the roof at the windshield header (Fig. 3). The pur-
pose of the paper is to protect the roof panel from
scratches, and to define the area to be demagnetized.

(7) Connect the degaussing tool to an electrical

outlet, while keeping the tool at least 61 centimeters
(2 feet) away from the compass unit.

(8) Slowly approach the center line of the roof

panel at the windshield header, with the degaussing
tool connected.

(9) Contact the roof panel with the plastic coated

tip of the degaussing tool. Be sure that the template
is in place to avoid scratching the roof panel. Using a
slow, back-and-forth sweeping motion, and allowing
13 millimeters (0.50 inch) between passes, move the
tool at least 11 centimeters (4 inches) to each side of
the roof center line, and 28 centimeters (11 inches)
back from the windshield header.

(10) With the degaussing tool still energized,

slowly back it away from the roof panel. When the
tip of the tool is at least 61 centimeters (2 feet) from
the roof panel, disconnect the tool.

(11) Calibrate the compass and adjust the compass

variance. Refer to Compass Variation Adjustment
and Compass Calibration in the Service Proce-
dures section of this group for the procedures.

REMOVAL AND INSTALLATION

OVERHEAD CONSOLE

REMOVAL

(1) Disconnect and isolate the battery negative

cable.

(2) Remove the screw that secures the front of the

overhead console to the front of the overhead console
retainer bracket.

(3) Insert the fingertips of both hands between the

headliner and the sides of the overhead console hous-
ing in the area near the reading and courtesy lamps.

(4) Pull downward on the sides of the overhead

console housing firmly and evenly to disengage the
two snap clips that secure the rear of the unit from
their receptacles in the overhead console retainer
bracket.

(5) Lower the overhead console from the headliner

far enough to access the wire harness connectors.

(6) Disconnect the roof wire harness connectors

from the Electronic Vehicle Information Center con-
nector receptacle, the reading and courtesy lamp wire
harness connector and, if the vehicle is so equipped,
from the back of the power sunroof switch.

Fig. 3 Roof Demagnetizing Pattern

8V - 10

OVERHEAD CONSOLE SYSTEMS

WJ

SERVICE PROCEDURES (Continued)

(7) Remove the overhead console from the head-

liner.

INSTALLATION

(1) Position the overhead console near the mount-

ing location on the headliner.

(2) Reconnect the roof wire harness connectors to

the Electronic Vehicle Information Center connector
receptacle, the reading and courtesy lamp wire har-
ness connector and, if the vehicle is so equipped, to
the back of the power sunroof switch.

(3) Align the two snap clips on the rear of the

overhead console housing with their receptacles in
the overhead console retainer bracket.

(4) Push upward firmly and evenly on the sides of

the overhead console housing over both of the snap
clip locations until each of the two snap clips is fully
engaged with its receptacle in the overhead console
retainer bracket.

(5) Install and tighten the screw that secures the

front of the overhead console housing to the overhead
console retainer bracket. Tighten the screw to 1.2
N·m (10 in. lbs.).

(6) Reconnect the battery negative cable.

ELECTRONIC VEHICLE INFORMATION CENTER

REMOVAL

(1) Disconnect and isolate the battery negative

cable.

(2) Remove the overhead console from the head-

liner. Refer to Overhead Console in the Removal
and Installation section of this group for the proce-
dures.

(3) Remove the four screws that secure the Elec-

tronic Vehicle Information Center (EVIC) module to
the overhead console housing (Fig. 4).

(4) Remove the EVIC module from the overhead

console housing.

INSTALLATION

(1) Position the EVIC module onto the overhead

console housing.

(2) Install and tighten the four screws that secure

the EVIC module to the overhead console housing.
Tighten the screws to 0.9 N·m (8 in. lbs.).

(3) Install the overhead console onto the headliner.

Refer to Overhead Console in the Removal and
Installation section of this group for the procedures.

(4) Reconnect the battery negative cable.

NOTE: If a new compass mini-trip computer has
been installed, the compass will have to be cali-
brated and the variance set. Refer to Compass Vari-
ation Adjustment and Compass Calibration in the
Service Procedures section of this group for the
procedures.

Fig. 4 Electronic Vehicle Information Center

Remove/Install

1 – OVERHEAD CONSOLE HOUSING
2 – EVIC MODULE
3 – ILLUMINATION LAMPS
4 – SCREWS (4)

WJ

OVERHEAD CONSOLE SYSTEMS

8V - 11

REMOVAL AND INSTALLATION (Continued)

AMBIENT TEMPERATURE SENSOR

REMOVAL

(1) Disconnect and isolate the battery negative

cable.

(2) Locate the ambient temperature sensor, on the

right side of the radiator opening in the headlamp
mounting module, behind the grille (Fig. 5).

(3) Remove the radiator grille fascia and insert

from the headlamp mounting module. Refer to Grille
in the Removal and Installation section of Group 23 -
Body for the procedures.

(4) Disconnect the wire harness connector from the

ambient temperature sensor connector receptacle.

(5) Remove the one screw that secures the ambient

temperature sensor bracket to the headlamp mount-
ing module.

(6) Remove the ambient temperature sensor from

the headlamp mounting module.

INSTALLATION

(1) Position the ambient temperature sensor onto

the radiator yoke.

(2) Install and tighten the one screw that secures

the ambient temperature sensor bracket to the radi-
ator yoke. Tighten the screw to 2.2 N·m (20 in. lbs.).

(3) Reconnect the wire harness connector to the

ambient temperature sensor connector receptacle.

(4) Install the radiator grille fascia and insert onto

the headlamp mounting module. Refer to Grille in
the Removal and Installation section of Group 23 -
Body for the procedures.

(5) Reconnect the battery negative cable.

SPECIAL TOOLS

OVERHEAD CONSOLE SYSTEMS

Fig. 5 Ambient Temperature Sensor Remove/Install

1 – AMBIENT TEMPERATURE SENSOR
2 – WIRE HARNESS CONNECTOR
3 – HEADLAMP MOUNTING MODULE

Degaussing Tool 6029

8V - 12

OVERHEAD CONSOLE SYSTEMS

WJ

REMOVAL AND INSTALLATION (Continued)

WIRING DIAGRAMS

CONTENTS

page

page

AIR CONDITIONING-HEATER . . . . . . . . . . . 8W-42-1
AIRBAG SYSTEM
. . . . . . . . . . . . . . . . . . . . 8W-43-1
ANTI-LOCK BRAKES
. . . . . . . . . . . . . . . . . . 8W-35-1
AUDIO SYSTEM
. . . . . . . . . . . . . . . . . . . . . 8W-47-1
BODY CONTROL MODULE
. . . . . . . . . . . . . 8W-45-1
CHARGING SYSTEM
. . . . . . . . . . . . . . . . . . 8W-20-1
COMPONENT INDEX
. . . . . . . . . . . . . . . . . . 8W-02-1
CONNECTOR LOCATIONS
. . . . . . . . . . . . . . 8W-90-1
CONNECTOR PIN-OUTS
. . . . . . . . . . . . . . . 8W-80-1
FRONT LIGHTING
. . . . . . . . . . . . . . . . . . . . 8W-50-1
FUEL/IGNITION SYSTEM
. . . . . . . . . . . . . . 8W-30-1
GENERAL INFORMATION
. . . . . . . . . . . . . . 8W-01-1
GROUND DISTRIBUTION
. . . . . . . . . . . . . . 8W-15-1
HORN/CIGAR LIGHTER/POWER OUTLET
. . 8W-41-1
INSTRUMENT CLUSTER
. . . . . . . . . . . . . . . 8W-40-1
INTERIOR LIGHTING
. . . . . . . . . . . . . . . . . . 8W-44-1
JUNCTION BLOCK
. . . . . . . . . . . . . . . . . . . . 8W-12-1
OVERHEAD CONSOLE
. . . . . . . . . . . . . . . . . 8W-49-1

POWER DISTRIBUTION . . . . . . . . . . . . . . . 8W-10-1
POWER DOOR LOCKS
. . . . . . . . . . . . . . . . 8W-61-1
POWER MIRRORS
. . . . . . . . . . . . . . . . . . . 8W-62-1
POWER SEATS
. . . . . . . . . . . . . . . . . . . . . . 8W-63-1
POWER SUNROOF
. . . . . . . . . . . . . . . . . . . 8W-64-1
POWER WINDOWS
. . . . . . . . . . . . . . . . . . . 8W-60-1
REAR LIGHTING
. . . . . . . . . . . . . . . . . . . . . 8W-51-1
REAR WINDOW DEFOGGER
. . . . . . . . . . . . 8W-48-1
SPLICE INFORMATION
. . . . . . . . . . . . . . . . 8W-70-1
SPLICE LOCATIONS
. . . . . . . . . . . . . . . . . . 8W-95-1
STARTING SYSTEM
. . . . . . . . . . . . . . . . . . 8W-21-1
TRAILER TOW
. . . . . . . . . . . . . . . . . . . . . . . 8W-54-1
TRANSMISSION CONTROL SYSTEM
. . . . . 8W-31-1
TURN SIGNALS
. . . . . . . . . . . . . . . . . . . . . . 8W-52-1
VEHICLE SPEED CONTROL
. . . . . . . . . . . . 8W-33-1
VEHICLE THEFT SECURITY SYSTEM
. . . . . 8W-39-1
WIPERS
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8W-53-1

WJ

WIRING DIAGRAMS

8W - 1
