279

Audio unit operation

STATION PRESET BUTTONS

Preset memorised radio stations (1
- 9)

On each waveband (AM, FM1, FM2), nine
stations can be memorised using the
touch-screen keypad buttons. After
tuning to a station, press and hold the
selected button until the station has been
stored. A station can be recalled from the
preset memory by pressing and
immediately releasing the button.

A long press of the steering wheel preset
selector button will cycle through the
preset stations. See AUDIO CONTROL
(page 79).

WARNING

In the interests of road safety, do
not attempt to preset a station
while driving.

Settings

A u d i o

AM / FM

Autostore

KSAN

PTY

3CH

93.5

WABC

WFAN

WXRP

KSAN

WPLJ

WQXR

WHTZ

WHUD

WCBS

12 : 26 pm

E93938

Audio unit menus

280

Audio unit menus

RADIO BROADCAST DATA
SYSTEM (RBDS)

Your radio is equipped with RBDS, which
enables the audio unit to receive
additional information with normal radio
signals.

When tuned to certain stations on the FM
waveband the radio decodes signals
transmitted to provide the following
functions (dependent upon the service
available from the broadcasters).

Note: Not all FM radio stations broadcast
RBDS. If a non-RBDS station is received,
RBDS features will not be available.
• RBDS station name display: When

RBDS is selected the station name is
displayed.

• RBDS Priority programme type auto

re-tuning (where broadcast): This can
be selected to interrupt and switch to
the selected programme type e.g.
News, for its duration or can be used
to search for specific PTY stations.

If the RBDS function does not respond
correctly, see the trouble-shooting guide.

RBDS trouble-shooting guide

PRIORITY PROGRAMME TYPE
(PTY)

The RBDS (Radio Broadcast Data
System) allows programmes to be
categorised by the broadcast type (rock
music, current affairs, news, etc).

This in turn allows you to search for a
station by choosing the type of broadcast
that you wish to listen to.

PTY selection

PTY (Programme type, where broadcast)
is selected from the Audio - Settings
display.

PTY has two functions:
• to set a desired priority programme

type

• to search for a programme type (PTY

Search) and re-tune to it.

Incorrect

response

from RDS

Reason and rectification

Radio does
not display
programme
name.

RBDS name is not
available from the
broadcast.

Station
name is lost
and displays
frequency
only.

Radio has lost reception
of the RBDS data due to
vehicle moving out of
transmitter range, loss of
signal in a tunnel, under a
garage forecourt canopy,
or similar screening. If the
latter is the case, when
the vehicle is clear of the
screening, the station
name will return after a
short delay.

281

Audio unit menus

Use the scroll buttons to cycle through
the available programme types (there are
30 types available), press the required
menu buttons to select the desired
programme types.

Priority programme type

Select the required priority programme,
then select the previous screen button.
The radio will now wait for RBDS
information to indicate that a station has
changed its programme type, e.g. to
NEWS. The radio will now re-tune to the
new station for the duration that it
remains on that programme type.

If the current station is already on the
selected priority programme type, then
when this station is lost, the radio will
attempt to find another with the correct
programme type.

Note: PTY interrupt feature is also active
in the CD mode.

PTY search

Once a desired programme type is
selected press the PTY search button. If
there is a station with the correct PTY,
then the radio will re-tune to it. If not, the
radio will indicate NO PTY and return to
the current station.

While PTY is displayed, a search of the
set PTY programmes can be carried out
by pressing the seek down or seek up
buttons.

Clear all will cancel ALL the selected
priority settings, except for PTY-Alarm,
and the PTY indicator will clear from the
display.

PTY-Alarm (where broadcast)

When using the radio with RBDS
selected, a PTY-Alarm service may be
activated from the menu, to alert on any
crises of major national importance.
When such a broadcast is made, ALARM
will appear in the audio display. The
default setting is ON.

A u d i o

Sound

Options

PTY

S e t t i n g s

Sound

Options

PTY

Rock

News

Information

Sports

Talk

Clear all

PTY

Search

12 : 26 pm

E93960

A u d i o

Sound

Options

PTY

S e t t i n g s

Sound

Options

PTY

Alert

Personality

Public

College

Weather

Clear all

PTY

Search

12 : 26 pm

E93961

Compact disc player

282

Compact disc player

LOADING COMPACT DISCS

Note: Some privately recorded CD-R
discs may not have been acceptably
formatted to be able to be played on this
CD player.

An in-dash 6 compact disc (CD) player is
installed in the touch-screen console and
it will accommodate up to six discs. It will
play Compact Disc Digital Audio (CDDA)
discs (normal discs), MP3 and WMA files.

The main Home screen display will
indicate which CD slot is loaded and
ready for playing. If no CDs have been
loaded, the touch-screen indicates the
unloaded state by displaying the six
ghosted discs.

To access the CD player touch-screen:
• From the main Home touch-screen

menu, select Audio.

• Select CD.

CAUTIONS

countries; please check the laws in your
country if you want to record from
copyright source material.

Due to technical incompatibility,
recordable (CD-R) discs and
re-writable (CD-RW) discs may not

function correctly.

These CD units will play compact
discs that conform to the
international Red Book standard

audio specification. Copy protected CDs
from some manufacturers do not
conform to this standard and playback
cannot be guaranteed.

Dual format, dual sided discs (DVD
Plus, CD-DVD format), now being
adopted by the music industry, are

thicker than normal CDs and
consequently playback cannot be
guaranteed in Jaguar audio units, and
jamming could occur. Warranty claims,
where this type of disc is found to be
inside an audio unit returned for repair,
will not be accepted.

Irregular shaped CDs and CDs with
a scratch protection film or self
adhesive labels attached should

not be used.

Do not force the disc into the slot.

Home

Audio

Climate

Phone

Navigation

Vehicle

External

Left

Right

Valet

12 : 26 pm

Tr 3

03:42

E93963

AM / FM

Settings

A u d i o

PTY

3CH

770

WABC

Text sent by station

WABC

WFAN

WXRP

WNYC

WPLJ

WQXR

WHTZ

WHUD

Autostore

WCBS

12 : 26 pm

E93964
