123

Information displays

R

Auto: Select On. Brightness and contrast
are automatically adjusted by the
ambient light level. As the light level
decreases the touch-screen brightness
will decrease until the full night screen
level of brightness is initiated.

Further adjustment of the touch-screen
brightness can be achieved by using the
+ or - buttons in the Cont./Bright screen
or by adjustment of the instrument panel
dimmer switch.  See INSTRUMENT
LIGHTING DIMMER (page 151).

Pop-up messages

The operation of certain functions will
cause a small message, pop-up, to
appear overlaying the touch-screen
display.

The pop-up is mainly for information and
will disappear automatically after a few
seconds, or can be dismissed by
touching the pop-up screen area.

If any action or adjustment is required the
message will clearly indicate what is
required and which button to touch.

Touch-screen systems

There are five major systems controlled
via the touch-screen with their individual
levels of operation and settings. They are
as follows:
• Audio
• Climate
• Phone
• Navigation
• Vehicle.

Audio system

The vehicle audio system interacts with
Navigation, In-car Telephone and Climate
Control systems.

The audio system can be controlled from
the switches on the touch-screen
console, the touch-screen buttons and
from the multi-function controls on the
left-hand side of the steering wheel.  See
AUDIO CONTROL (page 273).

Vehicle

Off

On

Auto dimming

Trip computer

Clock adjust

Cont./Bright.

Syst. settings

Veh. settings

Brightness

Contrast

12 : 26 pm

E91329

Vehicle

Off

On

Auto dimming

Trip computer

Clock adjust

Cont./Bright.

Syst. settings

Veh. settings

Brightness

Contrast

12 : 26 pm

E93844

Audio

Sound

Options

PTY

On

On

Off

Off

Audio

Cancel

AutoStore

Please wait..

Settings

12 : 26 pm

E93845

Information displays

124

L

The system structure is shown as a flow
chart at the end of this section.

Automatic climate control

The automatic climate control system
can be controlled from the touch-screen
buttons.  See AUTOMATIC CLIMATE
CONTROL (page 134).

Phone

The communications system is
composed of the following facilities:
• phone
• digit dialler
• phone book
• last ten calls made, received, missed.

The telephone system is controlled from
the touch-screen and the multi-function
controls on the left-hand side of the
steering wheel.  See AUDIO CONTROL
(page 79).

Navigation system

See the Navigation Handbook for
detailed information on the operation of
the navigation system.

Vehicle system

The following system functions are set
using the touch-screen:
• trip computer
• clock adjust
• contrast and brightness
• system settings
• vehicle settings.

The system structure is shown as a flow
chart at the end of this section.

Languages and distance units

The screen text and distance units are
available in various languages and either
Imperial or Metric units respectively.

The required languages and units are
accessed by selecting Vehicle on the
main system Home screen, then
selecting:
• Trip computer
• Unit change
• Preferences and then selecting from

the menu.

To change the units: The unit choices
are selected by pressing the buttons
either km, km/h l/100, or Mls. MPH
MPG.

Temperature display is selected by
pressing either °C or °F.

Note: Celsius or Fahrenheit may be
selected independently of metric or
Imperial units.

Vehicle

Display set

Preferences

Button audio

Mls. MPH MPG

km km/h 1/100

F

C

0

0

Display language

English US

Vol. presets

Change

12 : 26 pm

E93846

125

Information displays

R

To change the language: The language
choices are displayed as a list. Scroll up
or down through the list using the up or
down arrows.

Note: The navigation system is not
affected by the language change. To
change the navigation system language
display, refer to the Navigation
Handbook.

Timeout to home screen

The Timeout to home screen (return to
display the Home screen) can be
adjusted.

From the main Home screen select the
Vehicle button.

1 Select the Syst. settings button.

Select Display set, 2 followed by
Timeout to home screen either On or
Off , 3. Using the adjustment bar the time
out can be adjusted from ten seconds to
five minutes.

Note: An initial default setting of one
minute is set if no time adjustment is
made.

Menu structure

The following menu outlines represent
the touch-screen Audio, Vehicle and
Telephone system structure:

Vehicle

Display set

Preferences

Button audio

Mls. MPH MPG

km km/h 1/100

F

C

0

0

Display language

English UK

Vol. presets

Change

Vehicle

Dutch

Danish

Finnish

French

Norwegian

12 : 26 pm

12 : 26 pm

E93847

Vehicle

Trip  B

Auto

Reset

Unit  Ch

Distance

Av. speed

Av. fuel

500 miles

35 MPH

23 MPG

300 miles

Range

Clock adjust

Cont./Bright.

Trip computer

Syst. settings

Veh. settings

Trip  A

12 : 26 pm

E93848

Vehicle

Display set.

Preferences

Button audio

Vol. presets

12 : 26 PM

50 seconds

Screensaver set.

Timeout to home
screen

On

Off

3

2

E93849

Information displays

126

L

AM/FM

Settings

CD

Sound

Base

Treble

Balance
Fade

Option

AM/FM

Settings

CD

Sound

Base

Treble

Balance
Fade

Option

PTY

(choose from itemised list)

E93912

CD text

FM text
