Throttle Body - Vehicles Without: Removal
1 .
WARNING: When relieving cooling system pressure, cover the expansion tank cap with a thick cloth to prevent the possibility of scalding. Failure to follow these instructions may result in personal injury.
Remove the expansion tank cap to relieve the cooling system pressure.
2 .
CAUTION: Do not attempt to clean the throttle body. The bore and the throttle plate has a special coating applied during manufacture which should not be removed.
Remove the air outlet pipe. For additional information, refer to Air Cleaner Outlet Pipe (19.10.31)
3 . Disconnect the electrical connector.
4 . Disconnect the electrical connector. |
