4 . Detach the parking brake cable.

1) Release the retaining tangs.

2) Detach the parking brake cable.

CAUTION: Brake fluid contains polyglycol ethers and polyglycols. Avoid contact with

the eyes. Wash hands thoroughly after handling, as prolonged contact may cause irritation

and dermatitis. If brake fluid contacts the eyes, flush the eyes with cold water or eyewash

solution and seek medical attention. If taken internally do not induce vomiting, seek

immediate medical attention. Failure to follow these instructions may result in personal

injury.

CAUTION: If brake fluid comes into contact with the paintwork, the affected area

must be immediately washed down with cold water.

CAUTION: The brake caliper must be supported at all times.

CAUTION: Cap the brake hose to prevent loss of fluid and prevent dirt ingress.

To prevent the loss of brake fluid, apply the brake pedal hold-down tool and adjust to

hold the brake pedal down 40 mm (1.6 in).

Detach the brake hose.

Remove and discard the sealing washers.

6 . NOTE:

Left-hand shown, right-hand similar.

Remove the brake caliper.

1) Remove and discard the brake caliper retaining bolts.

2) Remove the brake caliper.

Installation

CAUTION: If brake fluid comes into contact with the paintwork, the affected area

NOTE:

www.

must be immediately washed down with cold water.

Install the brake caliper.

Install new brake caliper upper retaining bolts.

Tighten to 34 Nm.

2 . Attach the brake hose.

Install new sealing washers.

Tighten to 35 Nm.

3 . Attach the parking brake cable.

4 . Attach the parking brake cable.

1) Reposition the brake caliper lever.

2) Attach the parking brake cable.

5 . Remove the brake pedal hold-down tool.

Bleed the brake system.

For additional information, refer to

Brake System Bleeding - VIN Range: G00442->G45703

(70.25.03)

7 . Install both rear wheels and tires.

For additional information, refer to

Wheel and Tire (74.20.05)
