Jaguar XJ (X350). Manual - part 34

Item  Part Number

Description

1

 —

Maximum permitted front axle loading

2

 —

Date of manufacturer

3

 —

Maximum permitted rear axle loading

4

 —

Gross vehicle weight

5

 —

VIN

6

 —

Paint code

7

 —

Interior trim code

8

 —

Type



VIN Label (China)



Item  Part Number

Description

1

 —

VIN

2

 —

Date of manufacturer

3

 —

Occupant number

4

 —

Gross vehicle weight/Gross train weight

5

 —

Engine specification

6

 —

Vehicle type

7

 —

Trade mark



The serial number of the transmission unit is displayed on a metal label or bar code (if
equipped) attached to the transmission casing.

Engine Number - 3.0L

The engine number is contained on a bar code label on the front cover and is also stamped in
the cylinder block casting on the left-hand side of the engine below the engine mounting.

Engine Number - 2.7L Diesel

The engine number is stamped next to the emission code on the lower right-hand side of the
cylinder block near the engine mounting. In addition it is also shown together with engine
information stamped onto the camshaft cover plate.

Engine Number - 3.5L, 4.2L and 4.2L Supercharged

The engine number is stamped on an engine web on the left-hand side of the cylinder block
behind the engine mounting. The engine emission code is located on a lug under the exhaust
manifold towards the left-hand rear of the cylinder block.





Automatic Transmission Number

www.

100-02 : Jacking and lifting





Description and operation





Jacking

Safety Precautions

  WARNING: The jack provided with the vehicle is intended to be used in an

emergency for changing a deflated tire. To avoid damage to the vehicle, never use the
jack to raise the vehicle for any other purpose. Refer to the Driver Handbook when
using the jack supplied with the vehicle. Failure to follow these instructions may result
in personal injury.

The following safety precautions must be observed when raising the vehicle to carry out
service operations:

•



Never rely on a jack alone to support a vehicle. Always use suitable vehicle stands to
provide rigid support.

•



When working beneath a vehicle, whenever possible use a vehicle hoist instead of a
jack and vehicle stands.

•



Make sure that the vehicle is standing on firm, level ground before using a jack.

•



Do not rely on the parking brake alone; chock the wheels and put the automatic
transmission into Park if possible.

•



Check that any lifting equipment used has adequate capacity for the load being lifted
and is in correct working order.








Jacking – Armoured Vehicles

Safety Precautions

 WARNING: Make sure that any jacks or stands that are used on the vehicle have sufficient capacity to carry the

additional weight of the vehicle. Failure to follow these instructions may result in personal injury.



 WARNING: The jack provided with the vehicle is intended to be used in an emergency for changing a deflated tire.

To avoid damage to the vehicle, never use the jack to raise the vehicle for any other purpose. Refer to the Driver
Handbook when using the jack supplied with the vehicle. Failure to follow these instructions may result in personal
injury.


The following safety precautions must be observed when raising the vehicle to carry out service operations:



Never rely on a jack alone to support a vehicle. Always use suitable vehicle stands to provide rigid
support.



When working beneath a vehicle, whenever possible use a vehicle hoist instead of a jack and vehicle
stands.



Make sure that the vehicle is standing on firm, level ground before using a jack.



Do not rely on the parking brake alone; chock the wheels and put the automatic transmission into
Park if possible.



Check that any lifting equipment used has adequate capacity for the load being lifted and is in correct
working order.

Vehicle Weight

The weight of the vehicle is greater than the standard vehicle. Always make sure that any jacks, lifts or
hoists are capable of carrying these loads. All the jacking and lifting points for the vehicle are exactly the
same as the standard vehicle.

Description

Front   Rear   Total

Unladen

1402kg  1448kg  2850kg

Gross Vehicle Weight  1500kg  1720kg  3200kg
