JAC-J7. Manual - part 18
-21
Notes
There is lead, lead compound and oth鄄
er chemical compounds in the ends,
binding post and the relative acces鄄
sories. So wash hands after touching it.
Storage battery
There is maintenance free storage bat鄄
tery installed in your vehicle. If you want
to replace the storage battery, the part
number on volume of all the storage
battery shall be the same with that of
the original storage battery. See 野Gen鄄
eral Drawing of Engine Cabin冶 in this
section to confirm the position of the
storage battery.
Vehicle storage
If the vehicle will not run in at least three
weeks, the cathode cable of the storage
battery should be cut off, which will pre鄄
vent the storage battery from leakage.
Clear up binding post of storage battery
1. Shut off the ignition switch and draw
out the key.
2. Loosen and disassemble the cable
clip of the storage battery from the
binding post with spanner. Do cut off
the cathode binding post (要) of the
storage battery first.
3. Clear up the binding post with steel
wire brush and clearing tool for binding
post.
4. Check if there is white or light blue
powder on the binding post of the stor鄄
age battery. If there is, it shows the
binding post has been eroded.
5. Clear up the eroded substances with
water solution of sodium bicarbonate.
The water solution of sodium bicarbon鄄
ate will make bubbles and become
Notes
The acid liquor in the storage battery
will burn you, and the generated gas is
explosive. If you are not careful, you will
be seriously injured. See 野Jumper
Start冶 in this section to know of the re鄄
lated hints for avoiding damage when
working around the storage battery.
MO TORS
淫 It will cause damage to the vehicle
paint if the brake fluid splashes onto
the vehicle paint surface. So pay at鄄
tention not to splash the brake fluid on鄄
to the vehicle. If it does, clean it im鄄
mediately. See 野Appearance Curing冶
in this section.
Which kind of brake fluid to be added?
When it is required to add brake fluid,
you can only use JG4 brake fluid and
can only use new brake fluid in un鄄
opened container. See 野Main Fluid Pa鄄
rameters冶 in section II.
Before unscrew the stock solution tank
cover for brake fluid, you should clean
the tank cover and the components
around it. It can prevent the dirt from
going to the stock solution tank by do鄄
ing this.
Notes
If the type of brake fluid which is
added to the brake system is not cor鄄
rect, the brake can not work normally.
And it will cause accident. So, do use
the correct type of brake fluid.
淫 Using wrong type of brake fluid
will cause serious damage to the com鄄
ponents of brake system. For example,
adding only a few drops of mineral oil
to the brake system will cause serious
damage to the components of brake
system, and you have to replace these
components. Therefore, you should
prevent anyone to add the wrong type
of brake fluid.
-20
