Applied models: SUNRAY products manufactured by JAC

Tool

Tool

Tool

Tool Number

Number

Number

Number

Tool

Tool

Tool

Tool Name

Name

Name

Name

Illustration

Illustration

Illustration

Illustration

Function/Applied

Function/Applied

Function/Applied

Function/Applied Part

Part

Part

Part

JAC-T8F001

Piston pin puller

For removal/installation of engine piston pin

(engine)

JAC-T8F002

Handle

For installing bearing together with relevant

installer (transmission)

JAC-T8F003

Flywheel stopper

For fixing flywheel to facilitate removal (engine)

JAC-T8F004

Cooling system

detector

For checking engine cooling system for leakage

(engine)

JAC-T8F005

Oil filter wrench

For removal/installation of oil filter (engine)

JAC-T8F006

Valve oil seal

installer

For installation of valve oil seal (engine)

JAC-T8F007

Fuel pressure gauge

For measuring fuel pressure (engine)

JAC-T8F008

Compression

pressure gauge

For measuring engine cylinder pressure (engine)

JAC-T8F009

Pressure gauge

connector

For connection when measuring cylinder

pressure (engine)

JAC-T8F010

Valve spring

compressor

For compressing valve spring, removing engine

valves and relevant parts (engine)

JAC-T8F011

Camshaft gear puller

For removing camshaft gear (engine)

JAC-T8F012

Cylinder liner

installer (incl. jack)

For installing cylinder liner (engine)
