Isuzu Trooper (1998-2002 year). Manual - part 998
8D–526
WIRING SYSTEM
Parts Location (LHD 6VD1 Lever Type)
Legend
(1) I-9(2) H-7, H-8, H-25(3) Fuse Box(4) C-16(5) M-11, M-12(6) M-22
(7) M-23(8) M-24(9) H-10
(10) Relay and Fuse Box (X-18)(11) H-12
D08RW833
11
10
1
2
3
4
6
7
8
9
5
