Isuzu Trooper (1998-2002 year). Manual - part 942
8D–302
WIRING SYSTEM
Parts Location (RHD)
Legend
(1) B-13 or B-14(2) Shift Lever(3) H-32(4) B-2(5) B-26
(6) Shift Lock Controller (B-32)(7) B-18(8) Relay and Fuse Box(9) H-15
(10) Fuse Box
3
4
5
6
7
8
9
10
1
2
D08RWA08
