8D–234
WIRING SYSTEM
Parts Location (RHD)
Legend
(1) Horn Switch(2) Horn (Low Note)(3) C-28(4) C-27
(5) Horn (High Note)(6) Relay and Fuse Box (X-8)(7) Fuse Box(8) H-15, H-16(9) B-12
5
4
6
7
8
9
1
3
2
D08RW880
