8B–10 WIPER/WASHER SYSTEM Rear Wiper Arm/Blade Removal 1. Remove the arm nut(2). 885RS008 Installation Refer to the installation steps of the Rear Wiper Motor in Rear Washer Nozzle Removal 1. Disconnect the hose(3). nozzle(1). 885RS005 Installation To install, follow the removal steps in the reverse order. Rear Washer Nozzle Angle Loosen the lock nut(2) of the washer nozzle(1) to adjust 885RS004 |
