7A–36 AUTOMATIC TRANSMISSION (4L30–E) 5. Install the under cover (3 pieces), and tighten the bolts to the specified torque. Torque: 8 N • m (0.8 kg·m/69 lb in) 6. Install the starter, and tighten the bolts to the specified torque. Torque: 40 N • m (4.1 kg·m/30 lb ft) 7. Connect transmission harness connectors to transmission, and transfer. 8. Connect fuel pipe bracket to transmission side. For 4 × 4 141RW027 |
