6D3–21 STARTING AND CHARGING SYSTEM Disassembly 1. Terminal insulator and nut(2). terminal B and insulator, then remove the rear 060RW005 3. Remove two screws that fix the brush holder(5) and rectifier, then remove the brush holder assembly(4). 060RW004 4. Remove three screws on the IC regulator, then the IC regulator assembly(6). 060RW003 5. Remove four screws that fix rectifier(7) and stator lead wires. 066RW004 |
