6E–5

ENGINE DRIVEABILITY AND EMISSIONS

Specifications

Tightening Specifications

Application

N·m

Lb Ft.

Lb In.

Camshaft Position Sensor Retaining Screw

9

—

78

Crankshaft Position Sensor Mounting Bolt

10

—

87

EGR Bolt

28

21

—

EGR Nut

28

21

—

Engine Coolant Temperature Sensor

20

7.7

—

Fuel Drain Plug

29

22

—

Fuel Pressure Regulator Attaching Screw

6.5

—

60

Fuel Rail Bolts

25

18

—

Fuel Tank Undercover Retaining Bolts

36

27

—

Heated Oxygen Sensor

42

31

—

Lower Intake Manifold to Engine Block Bolts

25

18

—

Lower Intake Manifold to Engine Block Nuts

25

18

—

Spark Plugs

18

13

—

Throttle Body Mounting Bolts

25

18

—

Upper Intake Manifold to Lower Intake Manifold Bolts

25

18

—

VSS Retaining Bolt

13

—

120

Vehicle Type Specifications

EC

AUSTRALIA

THAILAND

SOUTH-EA

ST-ASIA

LATIN

AMERICA

GULF

CONTRIES

SAUDI

CHINA

SOU

TH

AFRI

CA

EXPORT

Specifications

UBS

UBS

UBS

UBS

UBS

UBS

OBD

O

2

SEN

CAT

EGR

MT

AT

MT

AT

MT

AT

MT

AT

MT

MT

AT

OBD

SEN

SOR

A

EGR

•

I

2

1

D

•

I

2

1

D

•

1

1

D

•

1

1

D

•

1

1

D

•

1

1

D

•

1

D

•

1

D

•

•

I

•

6E–6

ENGINE DRIVEABILITY AND EMISSIONS

Diagrams and Schematics

PCM Wiring Diagram (1 of 11)

D06RW00005

6E–7

ENGINE DRIVEABILITY AND EMISSIONS

PCM Wiring Diagram (2 of 11) For EC, THAILAND, SOUTH EAST ASIA, LATIN AMERICA,

GULF, SAUDI, CHINA.

D06RW134

6E–8

ENGINE DRIVEABILITY AND EMISSIONS

PCM Wiring Diagram (3 of 11) For SOUTH AFRICA and EXP.

D06RW140
