Isuzu Trooper (1998-2002 year). Manual - part 186
4D2–7
TRANSFER CASE (TOD)
TOD ECU
Removal
1. Disconnect the ground cable.2. Move the right-hand seat forward and remove the
second seat foot rest (1).
3. Disconnect the connector from the ECU (2).4. Remove the bolts and detach the ECU (2) from the
bracket.
F07RW021
Installation
1. Perform the removal step in reverse order.
