SUPPLEMENTAL RESTRAINT SYSTEM
9J–27
5–8840–0385–0 Connector Test Adapter
Kit
901RS151
The 5–8840–0385–0 Connector Test Adapter Kit must be
used whenever a diagnostic procedure requests
checking or probing a terminal. Using the appropriate
adapter will ensure that no damage to the terminal will
occur from the DVM prove, such as spreading or bending.
The adapter will also give an idea of whether contact
tension is sufficient, helping to find an open or intermittent
open due to poor terminal contact.
5–8840–2468–0 SRS Deployment Tool
901RW106
The 5–8840–2468–0 SRS Deployment Tool must be
used for deployment of the undeployed air bag, and/or
pretensioner seat belt.
5–8840–2420–0 SRS Deployment Fixture
901RW199
The 5–8840–2420–0 SRS Deployment Fixture must be
used for deployment of the undeployed passenger side
air bag.
5–8840–2469–0 SRS Adapter for Load
Tool.
901RW107
The 5–8840–2469–0 SRS Adapter for Load Tool must be
used with 5–8840–2421–0 SRS Driver/Passenger Load
Tool.
