EXTERIOR/INTERIOR TRIM 8J–37 Luggage Floor Box Luggage Floor Box and Associated 643RS006 Legend (1) Rear Seat Remove 1. Fold the rear seat assembly to the front direction. D Remove the clips which connect the floor carpet 3. Remove the luggage floor box. Installation To install, follow the removal steps in the reverse order. Rope Hook Set Rope Hook Set and Associated Parts 676RS003 Legend (1) Rope Hook Set Removal 1. Remove the rope hook set. D Open the hook cover and hook fixing bolt. Installation 1. Install the rope hook set. D Tighten the hook fixing bolt to the specified torque. Torque: 13 N·m (1.3kg·m/113 lb in) |
