DIFFERENTIAL (REAR 220mm) 4A2A–21 4. Adjust feeler gauge thickness from side to side until ring gear backlash is in the specified range. Backlash: 0.15–0.2 mm(0.006 –0.008 in) 425RS032 With zero end play and correct backlash estab- 5. Use bearing remover 5–8840–0013/0014–0 and pilot 5–8840–2196–0 to remove side bearing. 415RW032 13. Install the side bearings together with the selected shims. 425RS029 Legend (1) Drive Handle: 5–8840–0007–0 14. Install side bearing outer race. applied at disassembly. 425RS035 |
