SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL & COLUMN 2A – 73 Starter switch Setting cowl 7. Steering Column Cover When installing the steering column cover, be sure to 6. Steering Wheel Align the setting marks made when removing. CAUTION: Tighten the steering wheel fixing nut to the specified Steering Wheel Nut Torque N·m (kg·m/lb·ft) 34 (3.5 / 25) 5. Inflator Module 1) Support the module and carefully connect the module connector. CAUTION: • Never use the air bag assembly from another vehicle. • When replace the inflator module, use only same parts NOTE: 2) Secure the module with one bolt to relieve weight on the connector wire. 3) Tighten bolts to specified sequence as figure. Inflator Module Bolt Torque N·m (kg·m/lb·in) 8 (0.8 / 69) 4 Driver Knee Bolster (Reinforcement) 3. Steering Lower Cover Install the engine hood opening lever. 2. Lower Cluster Assembly 1. Front Console Assembly Connect the wiring harness connectors. Connect the yellow 2way SRS connector located Connect the battery ground cable. 825RS048 3 4 1 2 827RS017 |
