SUPPLEMENTAL RESTRAINT SYSTEM STEERING WHEEL & COLUMN 2A – 53
ON-VEHICLE SERVICE
2
1
827RW035
SRS CONNECTORS
CAUTION:
The special yellow color connectors are used for
supplemental restraint system-air bag circuit.
When removing the cable harness, do not pull the cables.
Otherwise, cable disconnection may occur.
When connect the SRS connector, insert the connector
completely. Imperfect locking may cause malfunction of
SRS circuit.
REMOVAL
To remove the connector, hold the cover insulator(1) and
pull it. The cover insulator slides and lock will be released.
Do not hold the socket insulator(2).
INSTALLATION
To install the connector, hold the socket insulator(1) and
insert it. The cover insulator slides and connector will be
locked.
Do not hold the cover insulator(2).
2
1
827RW034
