7A–36 AUTOMATIC TRANSMISSION (4L30–E) For 4 × 2 141RY001 10. Install transmission oil cooler pipe to transmission. Torque: 44 N • m (33 lb ft) 11. Install oil pipe clamp to torque converter housing bracket. 12. Tighten oil pipe clamp bolt at engine mount side. torque. Torque: 67 N • m (49 lb ft) 14. Install left catalytic converter assembly, and tighten the bolts to the specified torque. Exh. pipe to exh. manifold 67 N • m (49 lb ft) Exh. pipe flange bolt 43 N • m (32 lb ft) 15. Install left seat belt tension rod. Torque: 39 N • m (29 lb ft) 16. Connect two left side oxygen sensor connectors to the transmission harness. 17. Install front exhaust silencer mounting nuts. specified torque. Torque: 76 N • m (56 lb ft) 19. Install rear mount nuts, and tighten the bolts to the specified torque. Torque: 50 N • m (37 lb ft) 20. Remove the jack from the transfer case. |
