DRIVE LINE CONTROL SYSTEM (TOD) 4B2–56 Step Action Yes No 1 Turn on the starter switch. Is the battery voltage observed between terminals 14 and 46 or 34 The ECU has failed. Replace the ECU. Go to Step 2 Check the battery circuit. Go to Step 2 2 Check that all the parts are mounted. Is this step complete? Repeat the “Diagnosis Flow”. Return to Step 2 |
