6E–238 ENGINE DRIVEABILITY AND EMISSIONS 14 Drain sample fuel, visual inspection. — Verify repair Go to Step 15 15 Perform the procedure in Fuel System Pressure Test — Verify repair Go to Step 16 16 1. Check the injector connectors. 2. If any of the connectors are connected at an improper cylinder, connect as necessary. Was a problem found? — Verify repair Go to Step 17 17 Check for the following engine mechanical problems • Low compression • Leaking cylinder head gaskets • Worn camshaft • Camshaft drive belt slipped or stripped — Verify repair Go to Step 18 18 1. Review all diagnostic procedures within this table. 2. If all procedures have been completed and no malfunctions have been found, review/inspect the • Visual/physical inspection • Tech 2 data • All electrical connections within a suspected circuit and/or system Was a problem found? — Verify repair Go to Step 19 19 Is the ECM programmed with the latest software — Verify repair Go to Step 20 20 Replace the ECM. — Verify Repair — Step Action Value(s) Yes No |
