AUTOMATIC TRANSMISSION (AW30-40LE) 7A-205
248RY00029
Check piston stroke of direct clutch (C-2) Place the direct clutch assembly onto the OD support
248RY00061
Using a dial indicator, measure the direct clutch piston 2 or 57 – 114 psi) as shown. Piston stroke: 1.6 – 1.9 mm (0.0630 – 0.0748 in) (UBS) Pack clearance: 0.4 – 0.7 mm (0.0157 – 0.0276 in) (TFR/S)
1. Clutch drum thrust washer (Plastic)
248RY00002
5. Snap ring Place special tool on the spring retainer and compress 6. Piston return spring
248RY00030
7. Direct clutch drum Place the direct clutch drum onto the OD support. |
