MSG MODEL(2WD)  7B-109

SPECIAL SERVICE TOOL

(2WD) (MSG)

ITEM NO.

ILLUSTRATION

PART NO.

PART NAME

MTL-42

9-8529-2201-0

Spring pin remover

MTL-1

5-8840-0013-0

(J-22888)

Gear remover

MTL-9

5-8840-2001-0

(J-29768)

Holding fixture

MTL-35

5-8840-0353-0

(J-36629)

Mainshaft nut wrench

MTL-3

5-8840-0015-0

(J-22912-01)

Bearing remover/installer

MTL-13

5-8840-0026-0

(J-26540)

Front cover oil seal

installer

MTL-14

5-8522-0050-0

(J-29769)

Rear cover oil seal

installer

MTL-21

5-8840-0178-0

(J-33851)

Mainshaft collar installer

7B-110  MSG MODEL (4WD)

(4WD) (MSG)

ITEM NO.

ILLUSTRATION

PART NO.

PART NAME

MTL-36

5-8511-0011-0

(J-29041)

Thrust input hub nut

wrench

MTL-42

9-8529-2201-0

Spring pin remover

MTL-1

5-8840-0013-0

(J-22888)

Gear remover

MTL-9

5-8840-2001-0

(J-29768)

Holding fixture

MTL-35

5-8840-0353-0

(J-36629)

Mainshaft nut wrench

MTL-3

5-8840-0015-0

(J-22912-01)

Bearing remover/installer

MTL-32

5-8840-0133-0

(J-8614-01)

Output flange holder

MTL-11

5-8523-0010-0

(J-29040)

Output shaft Ft/Rr bearing

remover

OTL-1

5-8840-0007-0

(J-8092)

Driver handle

MSG MODEL(2WD)  7B-111

ITEM NO.

ILLUSTRATION

PART NO.

PART NAME

MTL-13

5-8840-0026-0

(J-26540)

Front cover oil seal

installer

MTL-14

5-8522-0050-0

(J-29769)

Rear cover oil seal

installer

MTL-21

5-8840-0178-0

(J-33851)

Mainshaft collar installer

TFMSG-WE-981

You are requested to order this manual using the
manual number that is shown above.

This manual is applicable for vehicles in all countries
except the USA, Canada, Europe and Thailand.

All rights reserved, This manual may not be
reproduced in whole or in part, without the permission
in writing of ISUZU MOTORS LIMITED.

Issued by

ISUZU MOTORS LIMITED

INTERNATIONAL SERVICE DEPARTMENT

Tokyo, Japan

First edition May., 1998

9805-01A-4
