8-164 ELECTRICAL-BODY AND CHASSIS HAZARD WARNING FLASHER SWITCH Removal 1. Instrument Panel Cluster Assembly • Refer to Section 10 “BODY” for instrument panel cluster assembly removal steps. 2. Hazard Warning Switch • Disconnect the switch connector. of the cluster assembly. Installation To install, follow the removal procedure in the reverse order. Connector Be absolutely sure that the hazard warning flasher switch 1 2 BACK UP LIGHT SWITCH Removal 1. Disconnect the connector 1 . 2. Remove the back up light switch from the transmission 2 . Installation Follow the removal procedure in the reverse order to install the Back up Light Switch Threads Apply liquid gasket to the threaded portion and install the back Connector Be absolutely sure that the back up light connector is securely |
