8–244 ELECTRICAL-BODY AND CHASSIS

Meter connector pin arrangement

W/ Tachometer (Gasoline engine)

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16

1 2 3 4 5 6 7

8 9 10 11 12 13 14 15 16

BLACK

B-24

B-23

WHITE

Connector

Ter-

No.

minal No.

1

Ground

2

Ignition

3

Tachometer

4

—

5

—

6

Engine coolant temperature gauge

7

—

8

O/D off indicator light (Australia: A/T)
Check trans warning light (6VD1 A/T)

9

Oil temp. warning light (Saudi Arabia
only)
Check engine warning light

10

Seat belt warning light (Saudi Arabia
only)
Diff. lock indicator light (South Africa
only)

11

—

12

—

13

Illumination light (+)

14

Illumination light (–)

15

4WD indicator light

16

Turn signal indicator light (left)

B-24

Connector

Ter-

No.

minal No.

1

Turn signal indicator light (right)

2

—

3

High-beam indicator light (+)

4

High-beam indicator light (–)

5

Ground

6

Power drive indicator (6VD1 A/T)

7

—

8

Speedometer

9

Speedometer

10

Oil pressure warning light

11

Fuel gauge

12

Brake warning light

13

Charge warning light

14

Illumination light (+)

15

Illumination light (–)

16

Fuel warning light

B-23

826RV033

ELECTRICAL-BODY AND CHASSIS 8–245

Meter connector pin arrangement

W/ Tachometer (Diesel engine)

1 2 3 4 5 6 7 8 9

10 11 12 13 14 15 16

1 2 3 4 5 6 7

8 9 10 11 12 13 14 15 16

BLACK

B-24

B-23

WHITE

Connector

Ter-

No.

minal No.

1

Ground

2

Ignition

3

Tachometer

4

—

5

—

6

Engine coolant temperature gauge

7

—

8

Glow indicator light

9

Sedimenter warning light

10

Seat belt warning light (Saudi Arabia
only)
Diff. lock indicator light (South Africa
only)

11

—

12

—

13

Illumination light (+)

14

Illumination light (–)

15

4WD indicator light

16

Turn signal indicator light (left)

B-24

Connector

Ter-

No.

minal No.

1

Turn signal indicator light (right)

2

—

3

High-beam indicator light (+)

4

High-beam indicator light (–)

5

Ground

6

—

7

—

8

Speedometer

9

Speedometer

10

Oil pressure warning light

11

Fuel gauge

12

Brake warning light

13

Charge warning light

14

Illumination light (+)

15

Illumination light (–)

16

Fuel warning light

B-23

826RV034

8–246 ELECTRICAL-BODY AND CHASSIS

SPEEDOMETER AND TACHOMETER

Speedometer On-Vehicle Inspection

Check the speedometer accuracy with a speedometer
tester.

Carefully follow the tester manufacturer’s instructions.

W/O Tachometer

Indication

Permissible Range

20

17.2–22.8

40

37.2–42.8

60

57.2–62.8

80

77.2–82.8

100

97.3–103.7

120

117.3–123.7

140

137.3–143.7

160

156.9–164.1

km/h meter (Except Saudi Arabia, South Africa)

km/h

826RV027

826RV039

W/Tachometer

826RV026

Indication

Permissible Range

20

20–25.6

40

40–45.6

60

60–65.6

80

80–85.6

100

99.5–105.9

120

119.5–125.9

140

139.5–145.9

160

159.1–166.3

km/h meter (Saudi Arabia, South Africa)

km/h

Indication

Permissible Range

20

18.2–21.8

40

38.2–41.8

60

58.2–61.8

80

78.8–82.8

100

98.5–103.1

MPH meter

MPH

Indication

Permissible Range

20

17.5–22.5

40

37.5–42.5

60

57.5–62.5

80

77.5–82.5

100

97.6–103.4

120

117.6–123.4

140

137.6–143.4

160

157.2–163.8

km/h meter (Except Saudi Arabia, South Africa)

km/h

W/O Tachometer

ELECTRICAL-BODY AND CHASSIS 8–247

Indication

Permissible Range

20

20–25

40

40–45

60

60–65

80

80–85

100

99.8–105.6

120

119.8–125.6

140

139.8–145.6

160

159.4–166

km/h meter (Saudi Arabia, South Africa)

km/h

826RV040

Speedometer Off-Vehicle Inspection

Remove the speedometer from the meter assembly and
measure the resistance and the current consumption
between each terminal.

Speedometer Resistance

Note: Use the analog type circuit tester (range: x 1k).

SEN

4P

IGN

GND

825RV064

Tester

terminal

Red (+)

Black (–) Black (–)

Red (+)

Terminal
symbol

IGN – GND

IGN

GND

IGN

GND

∞

30.6 – 37.4k

SEN – GND

SEN

GND

SEN

GND

28.8 – 35.2k

∞

4P – GND

4P

GND

4P

GND

13.5 – 16.5k

∞

Speedometer Current Consumption

Note: 1. Use the analog type circuit tester.

2. Since the current consumption fluctuates when

the source voltage varies, check to be sure that
the voltage applied is 12V ± 1V.

Terminal Current  Remarks

symbol

consumption

85 ± 15 mA

(when 12 ± 1V

No signal input

applied)

IGN – GND

,

.

W/O Tachometer

Indication

Permissible Range

20

18.5–21.5

40

38.5–41.5

60

58.5–61.5

80

79.1–82.5

100

98.9–102.7

MPH meter

MPH
