6E–120 4JH1 ENGINE DRIVEABILITY AND EMISSIONS Diagnostic Trouble Code (DTC) P0115 (Symptom Code 2) (Flash Code 14) Engine Coolant Temperature Sensor Circuit Low Input Step Action Value(s) Yes No 1 Was the “On-Board Diagnostic (OBD) System Check” — Go to Step 2 Go to On Board Diagnostic (OBD) System Check 2 1. Connect the Tech 2. 2. Review and record the failure information. 3. Select “F0: Read DTC Infor As Stored By ECU” in “F0: Diagnostic Trouble Codes”. Is the DTC P0115 (Symptom Code 2) stored as — Go to Step 3 Refer to Diagnostic Aids and Go to Step 3 3 1. Using the Tech 2, ignition “On” and engine “Off”. 2. Select “F1: Clear DTC Information” in “F0: Diagnostic Trouble Codes” with the Tech 2 and 3. Operate the vehicle and monitor the “F0: Read DTC Infor As Stored By ECU” in the “F0: Was the DTC P0115 (Symptom Code 2) stored in this — Go to Step 4 Refer to Diagnostic Aids and Go to Step 4 4 Check for poor/faulty connection at the ECT sensor or — Verify repair Go to Step 5 5 Visually check the ECT sensor. — Go to Step 8 Go to Step 6 93 2 1 89 E-41 C-57(B) |
