ELECTRICAL-BODY AND CHASSIS 8-281 3. Driver’s side door does not get locked (or unlocked) CheckpointTrouble Cause Count ermeasure Replace the door lock SW. Door lock SW. function SW. malfunction NG 4. FRT passenger’s side door does not get locked (or unlocked) Replace the FRT passenger’s side door lock actuator FRT passenger’s side door lock actuator function Actuator malfunction NG 5. RR door-RH does not get locked (or unlocked) Replace the RR door lock actuator-RH RR door lock actuator-RH function Actuator malfunction NG 6. RR door-LH does not get locked (or unlocked) Replace the RR door lock actuator-LH RR door lock actuator-LH function Actuator malfunction NG 7. Door lock does not operate when operated from the driver’s seat side Repair grounding point ( B-28 ) contact Poor grounding point contact NG Replace the door lock SW. Continuity between the door D-4 and 2 D-4 when the SW is locked and D-4 and 2 D-4 when the SW. SW. malfunction NG OK Grounding point ( B-28 ) |
