10-44  CAB

QUARTER GLASS (SPACE CAB)



  REMOVAL AND INSTALLATION

Removal Steps

1. Screw bolt

V

2. Quarter glass
3. Screw bolt
4. Screw bolt
5. Fastener assembly

Installation Steps

5. Fastener assembly
4. Screw bolt
3. Screw bolt
2. Quarter glass
1. Screw bolt

Important Operations - Removal

2. Quarter Glass
Pull out the glass assembly towards the rear of the vehicle.

CAB  10-45

FRONT SEAT

SPECIAL PARTS FIXING BOLT

N

⋅

m (kgf

⋅

m/lb

⋅

ft)

39.2

±±±±

9.8 (4

±±±±

1/28.9

±±±±

7.2)

39.2

±±±±

9.8 (4

±±±±

1/28.9

±±±±

7.2)

39.2

±±±±

9.8 (4

±±±±

1/28.9

±±±±

7.2)

10-46  CAB



  REMOVAL AND INSTALLATION

Removal Steps

1. Adjust cover
2. Bolt
3. Seat assembly
4. Adjuster

Installation Steps

4. Adjuster
3. Seat assembly

V

2. Bolt
1. Adjust cover

Important Operation - Installation

2. Bolt

Torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

39.2

±

 9.8 (4

±

 1 / 28.9

±

 7.2)

CAB  10-47

REAR SEAT



  REMOVAL AND INSTALLATION

Removal Steps

1. Rear seat cushion assembly

•

Release the lock, pull up the fixed
points.

2. Head rest
3. Rear seat back assembly

•

After removing the 2 fixing bolts,
remove the wire of the back from the
hook.

Installation Steps

V

3. Rear seat back assembly
2. Head rest
1. Rear seat cushion assembly

Important Operation - Installation

3. Rear Seat Back Assembly

Bolt torque

N

⋅

m(kgf

⋅

m/lb

⋅

ft)

19.6

±

 5 (2

±

 0.5 / 14.5

±

 3.6)
