THIRD SEAT

SE-57

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

THIRD SEAT

Exploded View

INFOID:0000000005147413

Third seat RH

ALIIA0070GB

1.

Headrest

2.

Headrest holder, locking

3.

Headrest holder, free

4.

Seatback board

5.

Seatback pad

6.

Seatback frame assembly

7.

Seatback cushion

8.

Seatback trim cover

9.

RH hinge cover

SE-58

< ON-VEHICLE REPAIR >

THIRD SEAT

Third seat LH

10. Seat motor/hinge assembly

11. Seat cushion

12. Seat cushion trim cover

13. Front link covers

14. Flex mat

15. Flex mat springs

16. Seat cushion frame assembly

17. Side link cover

18. LH hinge cover

ALIIA0071GB

1.

Headrest

2.

Headrest holder, locking

3.

Headrest holder, free

4.

Seatback board

5.

Seatback pad

6.

Seatback frame assembly

7.

Seatback cushion

8.

Seatback trim cover

9.

Seat cushion

THIRD SEAT

SE-59

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

LH Side Seat

INFOID:0000000005147414

REMOVAL

1. Remove the storage bin. Refer to

INT-19, "Removal and Installation"

.

2. Remove the lower base trim covers.
3. Remove front link nuts and the LH hinge front bolt.

4. Remove push pin (2) and release elastic band (3) from seat

frame (1).

•

⇐: Vehicle front

5. Partially lift seatback upright, then remove seat belt buckle (2)

from between hinge cover (1) and seat cushion side facing (3).

•

⇐: Vehicle front

6. Retract the seat into the cargo floor position.

10. Seat cushion trim cover

11. Front link covers

12. Flex mat

13.  Flex mat springs

14. Seat cushion frame assembly

15. Seat motor/hinge assembly

16. Control module/cross beam assem-

bly

17. LH hinge cover

18. Side link cover

19. RH hinge cover

LIIA2324E

LIIA2370E

LIIA2371E

SE-60

< ON-VEHICLE REPAIR >

THIRD SEAT

7. Remove the seat hinge rear bolt (A) and seat belt buckle bolt (B)

from the seat assembly.

CAUTION:

Discard the seat belt buckle bolt and use a new bolt for

installation.

8. Disconnect the seat harness.
9. Remove the seat assembly.

INSTALLATION

Installation is in the reverse order of removal.

Power seat cross beam

INFOID:0000000005147415

REMOVAL

1. Remove the lower seat mount bolts.
2. Fold the seat cushion up.

3. Remove the harness connectors from the seat control unit.

4. Press the front release tab and remove the seat control unit.

Seat belt buckle bolt

: Refer to

SB-8, "Removal and

Installation of Third Row Seat
Belt"

LIIA2325E

ALIIA0096GB

ALIIA0097ZZ

ALIIA0098ZZ
