PWC-116

< PRECAUTION >

PRECAUTIONS

5. When the repair work is completed, return the ignition switch to the

″LOCK″ position before connecting

the battery cables. (At this time, the steering lock mechanism will engage.)

6. Perform a self-diagnosis check of all control units using CONSULT-III.

POWER WINDOW MAIN SWITCH

PWC-117

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

ON-VEHICLE REPAIR

POWER WINDOW MAIN SWITCH

Removal and Installation

INFOID:0000000005147265

REMOVAL

1. Remove the power window main switch finisher (2) from the

door finisher LH. Refer to

INT-11, "Removal and Installation"

.

2. Using a suitable tool (A), remove the screws from the power win-

dow main switch (1), then release from the finisher (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA0856ZZ

PWC-118

< ON-VEHICLE REPAIR >

FRONT POWER WINDOW SWITCH

FRONT POWER WINDOW SWITCH

Removal and Installation

INFOID:0000000005147266

REMOVAL

1. Remove the front power window switch finisher (2) from the front

door finisher RH. Refer to

INT-11, "Removal and Installation"

.

: Pawl

2. Using a suitable tool (A), release the tabs and remove the front

power window switch (1).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA0857ZZ

REAR POWER WINDOW SWITCH

PWC-119

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

REAR POWER WINDOW SWITCH

Removal and Installation

INFOID:0000000005147267

REMOVAL

1. Remove the rear power window switch finisher (1) from the rear

door finisher. Refer to

INT-11, "Removal and Installation"

.

2. Using a suitable tool (A), release the tabs and remove the rear

power window switch (2).

INSTALLATION

Installation is in the reverse order of removal.

ALKIA0860ZZ
