Infiniti QX56 (JA60). Manual - part 760
PWC-52
< ECU DIAGNOSIS >
POWER WINDOW MAIN SWITCH
13
(G/Y)
2
Encoder pulse signal 1
Input
When power window mo-
tor operates.
14
(LG/W)
Ground Power window serial link
Input/
Output
IGN SW ON or power win-
dow timer operating.
15
(BR)
Ground Encoder power supply
Output
When ignition switch ON or
power window timer oper-
ates.
10
17
(B)
Ground Ground
—
—
0
19
(W/R)
Ground Battery power supply
Input
—
Battery voltage
Terminal No.
(Wire color)
Description
Condition
Voltage [V]
(Approx.)
+
–
Signal name
Input/
Output
JMKIA0070GB
JPMIA0013GB
