Infiniti QX56 (JA60). Manual - part 742
PG
HARNESS
PG-55
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
FRONT DOOR LH HARNESS
A4
R1
W/16
: To M1
C3 R107
W/8
: To R9
A4
R2
W/12
: To M2
C2 R108
B/6
: Rear air control (front)
D3 R3
W/2
: Vanity lamp LH
D2 R109
W/4
: Microphone
C3 R4
W/10
: Sunroof motor assembly
Room lamp sub-harness B
C2 R6
W/16
: To R101
D1 R200
W/16
: To B145
C3 R7
GR/10 : Auto anti-dazzling inside mirror
D1 R201
BR/24
: To B146
B3
R8
W/2
: Vanity lamp RH
C2 R202
W/12
: Video monitor
D3 R9
W/8
: To R107
D1 R203
W/3
: Personal lamp 2ND row
Room lamp sub-harness A
D2 R204
W/16
: Rear audio remote control unit
C2 R101
W/16
: To R6
E1
R205
W/3
: Personal lamp 3RD row
C3 R102
GR/8
: Front room/map lamp assembly
D2 R209
B/6
: Rear air control (rear)
D3 R104
GR/6
: Sunroof switch
E1
R210
W/2
: Over head console area antenna
ALMIA0215GB
D1
BR/24
: To M9
D9
GR/6
: Front power window motor LH
D2
W/16
: To M8
D10
BR/16
: Door mirror remote control switch
D3
W10
: To M158
D11
W/2
: Front step lamp LH
D4
W/16
: Door mirror LH
D12
W/2
: Front door speaker LH
D5
W/8
: Seat memory switch
D14
B/6
: Front door lock assembly LH
D7
W/16
: Main power window and door lock/unlock switch
D15
GR/2
: Front outside antenna LH
D8
W/3
: Main power window and door lock/unlock switch
D16
GR/2
: Front door request switch LH
