WARNING FUNCTION
DLK-39
< FUNCTION DIAGNOSIS >
[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
WARNING METHOD
The following table shows the alarm or warning methods with chime.
Combination meter shows information display when the warning conditions are met.
Engine start information
Ignition switch is ON posi-
tion
• Ignition switch: ON position.
• Shift position: P position
• Engine is stopped
Ignition switch is except
ON position
• Ignition switch: Except ON position.
• Shift position: P position
• Intelligent Key can be detected inside the vehicle.
Steering lock information
When steering lock can not be released after ignition switch is turned ON.
Intelligent Key low battery warning
When Intelligent Key has low battery, it is detected by BCM after ignition switch
is turned ON.
Key ID warning
When registered intelligent Key cannot be detected inside the vehicle after ig-
nition switch is turned ON.
Warning/Information functions
Operation procedure
Warning/Information functions
Combination meter display
Warning chime
Combination
meter buzzer
Intelligent
Key warning
buzzer
Intelligent Key system malfunction
—
—
—
OFF position warn-
ing
For internal
—
Activate
—
For external
—
—
Activate
P position warning
Activate
—
Take away warning
Door is open to
close
Activate
Activate
Door is open
—
—
Take away
through window
Activate
—
Door lock operation
warning
Request switch
operation
—
—
Activate
Intelligent Key
operation
—
—
Activate
Key ID warning
—
—
