DLN-204 < UNIT DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: R230] DIFFERENTIAL ASSEMBLY Disassembly INFOID:0000000006222421 1. Drain gear oil, if necessary. 2. Remove side flanges. 3. Remove rear cover mounting bolts. 4. Remove rear cover to insert the seal cutter [SST: KV10111100 CAUTION: • Never damage the mating surface. mating surface. 5. Using spacers, mount carrier on the attachment (A) [SST: 6. For proper reinstallation, paint matching marks on one side of CAUTION: • For matching marks, use paint. Never damage bearing caps and gear carrier. • Bearing caps are manufactured as integral molding. Use the matching marks to them in their original positions. 7. Remove bearing caps. : Apply Genuine Silicone RTV or equivalent. Refer to GI-22, "Recommended Chemical Products and Sealants" . : Apply Genuine High Strength Thread Locking Sealant or equivalent. Refer to GI-22, "Recommended Chemical Products Refer to for symbols not described above. PDIA0940E JSDIA0041ZZ SDIA1795E S-PD343 |
