DLK-50
< ECU DIAGNOSIS INFORMATION >
AUTOMATIC BACK DOOR CONTROL MODULE
DTC Index
INFOID:0000000006225863
NOTE:
Details of time display
• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1
→
2
→
3...38
→
39 after returning to the normal condition whenever ignition switch OFF
→
ON. The counter
remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF
→
ON after returning to the normal condition if the malfunction is detected again.
Priority
DTC
1
• B2425 AUTO BK DR CNT UNIT
• U1000: CAN COMM
• U1010: CONTROL UNIT (CAN)
• B2401 IGN OPEN
2
• B2403 PULSE ENCODER
• B2409 HALF LATCH SW
• B2416 TOUCH SEN R OPEN
• B2417 TOUCH SEN L OPEN
• B2419 OPEN SW
• B2420 CLOSE SW
• B2421 CLUTCH TIME OUT
• B2422 BACK DOOR STATE
• B2423 ABD MTR TIME OUT
• B2424 CLSR CONDITION
CONSULT-III display
Fail-safe
Item
Reference page
U1000: CAN COMM
—
CAN communication circuit
U1010: CONTROL UNIT(CAN)
—
Internal CAN communication circuit
B2401: IGN OPEN
×
IGN power supply circuit
B2403: PULSE ENCODER
×
Encoder signal
B2409: HALF LATCH SW
×
Half latch switch signal
B2416: TOUCH SEN R OPEN
×
Touch sensor RH
B2417: TOUCH SEN L OPEN
×
Touch sensor LH
B2419: OPEN SW
×
Open switch signal
B2420: CLOSE SW
×
Close switch signal
B2421: CLUTCH TIME OUT
×
Clutch operation time
B2422: BACK DOOR STATE
×
Back door state
B2423: ABD MTR TIME OUT
×
Automatic back door motor operation time
B2424: CLSR CONDITION
×
Closure condition
B2425: AUTO BCK DR CNT UNIT
—
Automatic back door control unit
