Infiniti QX56 (Z62). Manual - part 1205





SRC-24

< ECU DIAGNOSIS INFORMATION >

DIAGNOSIS SENSOR UNIT

B1122-B1127

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-111, "DTC
Logic"

.

B1129

SIDE MODULE RH
[OPEN]

Side air bag module RH circuit is open

SRC-112, "DTC
Logic"

.

B1130

SIDE MODULE RH
[VB-SHORT]

Side air bag module RH circuit is shorted to power supply cir-
cuit

SRC-114, "DTC
Logic"

.

B1131

SIDE MODULE RH
[GND-SHORT]

Side air bag module RH circuit is shorted to ground

SRC-116, "DTC
Logic"

.

B1132

SIDE MODULE RH
[SHORT]

Side air bag module RH circuits are shorted to each other

SRC-118, "DTC
Logic"

.

B1134

SIDE MODULE LH
[OPEN]

Side air bag module LH circuit is open

SRC-120, "DTC
Logic"

.

B1135

SIDE MODULE LH
[VB-SHORT]

Side air bag module LH circuit is shorted to power supply circuit

SRC-122, "DTC
Logic"

.

B1136

SIDE MODULE LH
[GND-SHORT]

Side air bag module LH circuit is shorted to ground

SRC-124, "DTC
Logic"

.

B1137

SIDE MODULE LH
[SHORT]

Side air bag module LH circuits are shorted to each other

SRC-126, "DTC
Logic"

.

B1138-B1143

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-128, "DTC
Logic"

B1144

CONTROL UNIT
[MISS INSTALLATION]

Air bag diagnosis sensor unit is malfunctioning or out of the
specified specification

SRC-129, "DTC
Logic"

.

B1145

CURTAIN MODULE RH
[OPEN]

Rear curtain air bag module RH circuit is open

SRC-130, "DTC
Logic"

.

B1146

CURTAIN MODULE RH
[VB-SHORT]

Rear curtain air bag module RH circuit is shorted to power sup-
ply circuit

SRC-132, "DTC
Logic"

.

B1147

CURTAIN MODULE RH
[GND-SHORT]

Rear curtain air bag module RH circuit is shorted to ground

SRC-134, "DTC
Logic"

.

B1148

CURTAIN MODULE RH
[SHORT]

Rear curtain air bag module RH circuits are shorted to each
other

SRC-136, "DTC
Logic"

.

B1150

CURTAIN MODULE LH
[OPEN]

Rear curtain air bag module LH circuit is open

SRC-138, "DTC
Logic"

.

B1151

CURTAIN MODULE LH
[VB-SHORT]

Rear curtain air bag module LH circuit is shorted to power sup-
ply circuits

SRC-140, "DTC
Logic"

.

B1152

CURTAIN MODULE LH
[GND-SHORT]

Rear curtain air bag module LH circuit is shorted to ground

SRC-142, "DTC
Logic"

.

B1153

CURTAIN MODULE LH
[SHORT]

Rear curtain air bag module LH circuits are shorted to each
other

SRC-144, "DTC
Logic"

.

B1154-B1159

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-146, "DTC
Logic"

.

B1170-B1175

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-147, "DTC
Logic"

.

B1177

PRE-TEN2 FRONT RH
[OPEN]

Lap pre-tensioner RH circuit is open

SRC-148, "DTC
Logic"

B1178

PRE-TEN2 FRONT RH
[VB-SHORT]

Lap pre-tensioner RH circuit is shorted to power supply circuit

SRC-149, "DTC
Logic"

B1179

PRE-TEN2 FRONT RH
[GND-SHORT]

Lap pre-tensioner RH circuit is shorted to ground

SRC-150, "DTC
Logic"

B1180

PRE-TEN2 FRONT RH
[SHORT]

Lap pre-tensioner RH circuits are shorted to each other

SRC-151, "DTC
Logic"

B1182

PRE-TEN2 FRONT LH
[OPEN]

Lap pre-tensioner LH circuit is open

SRC-152, "DTC
Logic"

DTC

Diagnostic item

Explanation

Reference page

DIAGNOSIS SENSOR UNIT

SRC-25

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

I

J

K

L

M

A

B

SRC

N

O

P

B1183

PRE-TEN2 FRONT LH
[VB-SHORT]

Lap pre-tensioner LH circuit is shorted to power supply circuit

SRC-153, "DTC
Logic"

B1184

PRE-TEN2 FRONT LH
[GND-SHORT]

Lap pre-tensioner LH circuit is shorted to ground

SRC-154, "DTC
Logic"

B1185

PRE-TEN2 FRONT LH
[SHORT]

Lap pre-tensioner LH circuits are shorted to each other

SRC-155, "DTC
Logic"

B1186-B1191

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-156, "DTC
Logic"

.

B1193

CURTAIN MODULE RH
[OPEN]

Front curtain air bag module RH circuit is open

SRC-157, "DTC
Logic"

B1194

CURTAIN MODULE RH
[VB-SHORT]

Front curtain air bag module RH circuit is shorted to power sup-
ply circuit

SRC-159, "DTC
Logic"

B1195

CURTAIN MODULE RH
[GND-SHORT]

Front curtain air bag module RH circuit is shorted to ground

SRC-161, "DTC
Logic"

B1196

CURTAIN MODULE RH
[SHORT]

Front curtain air bag module RH circuits are shorted to each
other

SRC-163, "DTC
Logic"

B1198

CURTAIN MODULE LH
[OPEN]

Front curtain air bag module LH circuit is open

SRC-165, "DTC
Logic"

B1199

CURTAIN MODULE LH
[VB-SHORT]

Front curtain air bag module LH circuit is shorted to power sup-
ply circuits

SRC-167, "DTC
Logic"

B1200

CURTAIN MODULE LH
[GND-SHORT]

Front curtain air bag module LH circuit is shorted to ground

SRC-169, "DTC
Logic"

B1201

CURTAIN MODULE LH
[SHORT]

Front curtain air bag module LH circuits are shorted to each
other

SRC-171, "DTC
Logic"

B1202-B1207

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-173, "DTC
Logic"

.

B1209

FRONTAL COLLISION DETEC-
TION

Seat belt pre-tensioner, driver air bag and passenger air bag
are deployed

SRC-174, "De-
scription"

.

B1210

SIDE COLLISION DETECTION

Side air bag, curtain air bag and seat belt pre-tensione are de-
ployed

SRC-175, "DTC
Logic"

.

B1211

ROLLOVER DETECTION

Curtain air bag and seat belt pre-tensione are deployed

SRC-176, "DTC
Logic"

B1212-B1214

RH1 SAT-SENS

Satellite sensor RH is malfunctioning

SRC-177, "DTC
Logic"

.

B1215-B1217

LH1 SAT-SENS

Satellite sensor LH is malfunctioning

SRC-179, "DTC
Logic"

.

B1218-B1223

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-181, "DTC
Logic"

.

B1234-B1239

CONTROL UNIT

Air bag diagnosis sensor unit is malfunctioning

SRC-182, "DTC
Logic"

B1304

SATELLITE SENS RH
[UNIT FAIL]

Rear satellite sensor RH is malfunctioning

SRC-183, "DTC
Logic"

B1306
B1308
B1309
B1310

SATELLITE SENS RH
[COMM FAIL]

Rear satellite sensor RH is malfunctioning

SRC-185, "DTC
Logic"

B1307

SATELLITE SENS RH
[UNMATCH]

Rear satellite sensor RH is out of the specified specification

SRC-187, "DTC
Logic"

B1311

SATELLITE SENS LH
[UNIT FAIL]

Rear satellite sensor LH is malfunctioning

SRC-188, "DTC
Logic"

DTC

Diagnostic item

Explanation

Reference page

SRC-26

< ECU DIAGNOSIS INFORMATION >

DIAGNOSIS SENSOR UNIT

B1313
B1315
B1316
B1317

SATELLITE SENS LH
[COMM FAIL]

Rear satellite sensor LH is malfunctioning

SRC-190, "DTC
Logic"

B1314

SATELLITE SENS LH
[UNMATCH]

Rear satellite sensor LH is out of the specified specification

SRC-192, "DTC
Logic"

DTC

Diagnostic item

Explanation

Reference page

SRS AIR BAG SYSTEM

SRC-27

< WIRING DIAGRAM >

C

D

E

F

G

I

J

K

L

M

A

B

SRC

N

O

P

WIRING DIAGRAM

SRS AIR BAG SYSTEM

Wiring Diagram

INFOID:0000000006219957

JCHWM0726GB
