Infiniti QX56 (Z62). Manual - part 53

AV-66

< ECU DIAGNOSIS INFORMATION >

VIDEO DISTRIBUTOR

29

—

Shield

—

—

—

—

30

—

Shield

—

—

—

—

31

(Y/L)

Ground

Composite image signal
ground for headrest display
unit LH

—

Ignition

switch

ON

—

0  V

32

(Y/G)

Ground

Composite image signal for
headrest display unit LH

Output

Ignition

switch

ON

When DVD, USB, front
AUX or rear AUX image is
displayed on headrest dis-
play unit LH.

33

(L)

Ground

Composite image signal
ground

—

Ignition

switch

ON

—

0  V

34

(P)

Ground

Composite image signal

Input

Ignition

switch

ON

When DVD, USB or front
AUX image is displayed on
headrest display unit LH or
RH.

35

—

Shield

—

—

—

—

40

(LG)

39

(V)

AUX image signal

Input

Ignition

switch

ON

When rear AUX image is
displayed on headrest dis-
play unit LH or RH.

41

—

Shield

—

—

—

—

45

(W)

46

(R)

Sound signal LH

Input

Ignition

switch

ON

When DVD, USB or front
AUX mode is selected on
headrest display unit LH or
RH.

47

(B)

48

(G)

Sound signal RH

Input

Ignition

switch

ON

When DVD, USB or front
AUX mode is selected on
headrest display unit LH or
RH.

49

—

Shield

—

—

—

—

53

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB2251J

SKIB2251J

SKIB2251J

SKIB3609E

SKIB3609E

AV

VIDEO DISTRIBUTOR

AV-67

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

54

(B)

56

(R)

AUX sound signal LH

Input

Ignition

switch

ON

When rear AUX mode is
selected on headrest dis-
play unit LH or RH.

55

(W)

56

(R)

AUX sound signal RH

Input

Ignition

switch

ON

When rear AUX mode is
selected on headrest dis-
play unit LH or RH.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

AV-68

< ECU DIAGNOSIS INFORMATION >

BOSE AMP.

BOSE AMP.

Reference Value

INFOID:0000000006216231

TERMINAL LAYOUT

PHYSICAL VALUES

JSNIA0760ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(R/B)

2

(W/B)

Sound signal squawker LH

Output

Ignition

switch

ON

Sound output

4

(L)

3

(O)

Sound signal squawker RH

Output

Ignition

switch

ON

Sound output

10

(R)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

11

(W/B)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

12

(B)

—

Ground

—

Ignition

switch

ON

—

0  V

13

(W)

8

(R)

Sound signal woofer

Output

Ignition

switch

ON

Sound output

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE AMP.

AV-69

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

14

(V)

9

(L)

Sound signal rear door
speaker RH

Output

Ignition

switch

ON

Sound output

16

(R)

17

(W)

Sound signal roof speaker
LH and RH

Output

Ignition

switch

ON

Sound output

18

(V)

19

(Y)

Sound signal front door
speaker LH

Output

Ignition

switch

ON

Sound output

20

(W/B)

Ground

BOSE amp. ON signal

Input

Ignition

switch

ON

—

12.0 V

24

(V)

23

(LG)

Sound signal rear LH

Input

Ignition

switch

ON

Sound output

26

(O)

25

(W)

Sound signal rear RH

Input

Ignition

switch

ON

Sound output

28

(L)

15

(R/Y)

Sound signal rear door
speaker LH

Output

Ignition

switch

ON

Sound output

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E
